Main Features:
- Series Turbo HD Version 5.0
- It allows to turn off the analog channels (TURBOHD) and to be able to place IP cameras on all channels, its possible to place up to 24 IP cameras in total. For each TURBOHD analog channel that is turned off, an additional IP channel is generated.
- The DVR support five technologies: HD-TVI / HD-CVI / Analog (CVBS) / AHD / IP.
- Remote access: PC (WINDOWS / MAC), SmartPhone (iPhone, iPad, Android).
- Compatible with Internet Explorer.
- Software client multi-site of up to 64 channels (iVMS-4200).
- Compatible with Hik-Connect P2P.
- Supports service DDNS Hik-Connect Domain / DynDNS.
- Advanced functions: Line-cross detection and intruder detection.
- Audio: 1 input and 1 output.
- Supports 1 HDD of up to 10 TB (not included).
- Serial interface: RS-485 (HIKVISION C, COAXITRON, PELCO D, PELCO P, etc).
Physical and Electrical Characteristics:
- Power supply: 12 Vdc (includes source).
- Consumption with HDD: 24 watts.
- Operating temperature: -10 ºC up to 55 ºC.
- Dimensions: 315 x 242 x 45 mm (W × D × H)
- Weight: 2.0 Kg without HDD.
- Warranty: 4 Years.
Compression and resolution:
- Compression: H.265+ / H.265 / H.264+ / H.264.
- Supports 16 channels TURBOHD / analog + 8 channels IP = 24 channels in total.
- Supports 5 Technologies (TVI / AHD / CVI / CVBS / IP):
- 4 Megapixel Lite@ 15 IPS
- 3 Megapixel @ 15 IPS
- 2 Megapixel @ 30 IPS
- 1 Megapixel @ 30 IPS
- Analog 1200TVL (CVBS) @ 30 IPS
- IP up to 6 Megapixel
- Note: Accepts cameras of 4MP, 2MP, and 1MP in all BNC channels (3MP cameras only in channels 1, 2, 3, and 4).
Outstanding Features:
The DVR also supports 4 video channels with activation of human body detection or vehicle detection, this allows us to be more precise when having a recording to be able to download any other type of movements
It is necessary to consider which of the analytics will be used since it is not possible to use both at the same time. When using the facial detection analytic it is not possible to activate the human body detection or vehicle detection or vice versa, when activating the human body detection or vehicle detection it is not possible to use the face detection analytic.
