Access Control:
Compatible with EPSON and RONGTA serial printers
The ticket format cannot be modified.
It is possible to choose which elements will be printed.
-
Relay output.
-
Alarm output to generate programmed audible alarms.
-
Request to exit button input.
Compatible with EPSON and RONGTA serial printers
The ticket format cannot be modified.
It is possible to choose which elements will be printed.
- Company name
- User ID
- Name
- Punch Time
- Punch State
- Device ID
- Print Time
- Verification Mode
*Power Supply Not Included
Technical Specifications:
|
Face Capacity |
1,500 |
|
Fingerprint Capacity |
2,000 |
|
ID Card Capacity (optional) |
2,000 |
|
Record Capacity |
100,000 |
|
Display |
2.8-inch TFT Screen |
|
Communication |
TCP/IP, ADMS USB-Host, Wi-Fi (Optional) |
|
Standard Functions |
SMS, DTS, Scheduled-bell, Self-Service Query, Automatic Status Switch, T9 Input, Photo ID, Camera, Multi-verification, 12V Output, RS232 Printer (Optional Cable) |
|
Optional Functions |
ID / MF Cards, Work Code |
|
Interface fot Access Control |
3rd Party Electric Lock, Exit Button, Alarm |
|
Power Supply |
DC 12V 1.5A |
|
Verification Speed |
≤ 1Sec. |
|
Operating Temp. |
0°c - 45°c |
|
Operating Humidity |
20% - 80% |
|
Dimension |
167.5 x 148.8 x 32.2 mm (Length*Width*Thickness) |
