Bosch D8128D Radionics Expander Module

Bosch · Intrusion & Alarm

Bosch D8128D OctoPOPIT 8-Point Expansion Module for Radionics Control Panels

Part number / SKU
D8128D

Works with: D9412GV2 control panel, D7412GV2 control panel, D7212GV2 control panel, D9412G control panel, D7412G control panel, D7212G control panel and 8 more models Confirmed by the manufacturer

$38.99

Special order· Lead time confirmed by our team after you order.

Warranty
Manufacturer warranty

Need project or contract pricing?

Request project pricing

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The Bosch D8128D OctoPOPIT is an eight-point expander that adds 8 off-board points to a Bosch (Radionics) control panel. Each point is supervised with a 1 k ohm end-of-line resistor, and the module includes a set of DIP switches.

The module runs on 12 VDC nominal and draws 25 mA maximum on standby and 50 mA maximum in alarm. It can sit up to 200 ft (60 m) from the control panel in a separate enclosure, wires to a terminal strip or to Molex connectors when several modules are used, and operates from 32 to 120 F (0 to 49 C).

Bosch lists it for the D9412GV2, D7412GV2, D7212GV2, D9412G, D7412G, D7212G, D9412, D7412 and D7212 panels; the D7212 models are not listed for commercial fire use. Mounting options include the D137 bracket in D8103, D8108A or D8109 enclosures.

  • Best for: adding eight hardwired points to a Bosch G Series or earlier Radionics intrusion panel.
  • System fit: Bosch D9412GV2, D7412GV2, D7212GV2, D9412G, D7412G, D7212G, D9412, D7412 and D7212 control panels.
  • Important to know: installation and programming should be done by a qualified alarm technician; the D7212 models are not listed for commercial fire applications.

Why teams choose it

Built for secure sites

  • Eight more points

    expands the panel with 8 supervised off-board points.

  • Low current

    25 mA standby and 50 mA alarm maximum at 12 VDC.

  • Remote mounting

    up to 200 ft from the panel in a separate enclosure.

  • Multi-module wiring

    terminal strip or Molex connectors when several modules are installed.

Specifications

Technical specifications

General
Brand Bosch
Model D8128D
Device Type OctoPOPIT eight-point expander module
Configuration On-board DIP switches
Zones 8 off-board points
Point Supervision 1 k ohm end-of-line resistor
Maximum Loop Resistance 100 ohms
Loop Response Time 1 second
Wire Size 22 AWG to 18 AWG for runs up to 200 ft
Wiring Terminal strip, or Molex connectors for multiple modules
Maximum Distance 200 ft (60 m) from the control panel in a separate enclosure
Compatible Panels D9412GV2, D7412GV2, D7212GV2, D9412G, D7412G, D7212G, D9412, D7412, D7212
Included OctoPOPIT module, hardware pack, literature pack
Electrical
Operating Voltage 12 VDC nominal
Standby Current 25 mA maximum
Alarm Current 50 mA maximum
Physical
Mounting D137 mounting bracket in D8103, D8108A or D8109 enclosures
Environmental
Operating Temperature 32 F to 120 F (0 C to 49 C)
