DSC WS4965 Wireless Tri-Zone Door/Window Contact 433MHz

DSC · Intrusion & Alarm

DSC WS4965 Tri-Zone Wireless Door/Window Contact, 433 MHz

Part number / SKU
WS4965
  • 1 CR123A lithium battery

Works with: PC5132-433 receiver, PC4164-433 receiver, NT9005-433 receiver, RF5501-433 receiver, RF5108-433 receiver Confirmed by the manufacturer

$31.99

In stock

Warranty
Manufacturer warranty

Need project or contract pricing?

Request project pricing

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The DSC WS4965 is a 433 MHz TriZone wireless door and window contact. Zone 1 is the built-in reed or tilt switch and zones 2 and 3 are normally closed external contact inputs, each with its own serial number, so one transmitter can protect up to three points. It works with PC5132-433, PC4164-433, NT9005-433, RF5501-433 and RF5108-433 receivers.

External contact wire runs can be up to 25 ft (7.6 m), and the magnet mounts within 1/2 in (1.27 cm) of the unit. It runs on one Panasonic CR123A lithium battery rated for 5 to 8 years, sends periodic supervisory signals, and reports a tamper to the panel when the cover is removed. The unit measures 75 x 43 x 25 mm and operates from -10 to 49 C at 5 to 93 percent relative humidity.

  • Best for: protecting a door or window plus two nearby hardwired contacts with one transmitter.
  • System fit: PC5132-433, PC4164-433, NT9005-433, RF5501-433, RF5108-433 receivers.
  • Important to know: UL/ULC listed for residential use only; tilt switch mode is not for UL installations, and external contacts must be in the same room as the unit.

Why teams choose it

Built for secure sites

  • Three zones

    internal reed or tilt switch plus two external contact inputs.

  • Hardwired inputs

    connect normally closed contacts up to 25 ft (7.6 m) away.

  • Tamper reporting

    cover removal reports a tamper to the panel.

  • Long battery life

    5 to 8 years on one CR123A lithium cell.

Specifications

Technical specifications

General
Brand DSC
Model WS4965
Device Type TriZone wireless door/window contact
Zones 3: reed or tilt switch plus 2 external contact inputs
Input Type Normally closed external contacts
External Wiring Up to 25 ft (7.6 m)
Magnet Gap 1/2 in (1.27 cm) maximum
Opening Limit Install so a door or window cannot open more than 2 in (51 mm) without alarm
Supervision Periodic supervisory signals
Tamper Cover removal reported as a zone tamper
Wireless
Wireless Frequency 433 MHz
Compatible Receivers PC5132-433, PC4164-433, NT9005-433, RF5501-433, RF5108-433
Electrical
Power Supply 1 CR123A lithium battery
Power Supply Detail Panasonic
Battery Life 5 to 8 years (not tested by UL/ULC)
Physical
Dimensions 75 x 43 x 25 mm (2-15/16 x 1-11/16 x 1 in)
Environmental
Operating Temperature -10 to 49 C (14 to 120 F)
Humidity 5 to 93 percent RH
Listings and Approvals
Agency Approvals UL/ULC listed for residential use only
UL Limitations Tilt switch mode not for UL installations; external contacts must be in the same room
Certifications FCC ID F5305WS4965; IC 160A-WS4965
