MikroTik · Wireless Access Points
MikroTik RBD25G-5HPacQD2HPnD Tri-Band Wireless Access Point
- EhubAmerica SKU
- RBD25G-5HPacQD2HPnD
Special order· Lead time confirmed by our team after you order.
- Warranty
- Manufacturer warranty
Need project or contract pricing?
Request project pricing- Help in English, Spanish and Portuguese
- 30-day returns
Not sure it fits your system? Check compatibility
Overview
What it is and who it is for
PRODUCT OVERVIEW
Wi-Fi has to be fast, reliable, easy to manage, it must reach every room and every corner. That is exactly what Audience devices can deliver in grand style – even in the biggest houses!
PRODUCT TYPE
Wireless Access Points
KEY FEATURES
• Specifications Product code: RBD25G-5HPacQD2HPnD
• Architecture: ARM 32bit
• CPU: IPQ-4019
• CPU core count: 4
• CPU nominal frequency: 716 MHz
• Switch chip model: IPQ-4019
• Dimensions: 100 x 235 x 97 mm
• RouterOS license: 4
• Operating System: RouterOS
• Size of RAM: 256 MB
• Storage size: 128 MB
• Storage type: NAND
• MTBF: Approximately 200'000 hours at 25C
• Tested ambient temperature: -40°C to 60°C
• IPsec hardware acceleration: Yes
• Wireless capabilities Wireless 2.4 GHz Max data rate: 300 Mbit/s
• Wireless 2.4 GHz number of chains: 2
• Wireless 2.4 GHz standards: 802.11b/g/n
TECHNICAL SPECIFICATIONS
• Brand: MikroTik
• Model: RBD25G-5HPacQD2HPnD
• Product Type: Wireless Access Points
• Specifications Product code: RBD25G-5HPacQD2HPnD
• Architecture: ARM 32bit
• CPU: IPQ-4019
• CPU core count: 4
• CPU nominal frequency: 716 MHz
• Switch chip model: IPQ-4019
• Dimensions: 100 x 235 x 97 mm
• RouterOS license: 4
• Operating System: RouterOS
• Size of RAM: 256 MB
• Storage size: 128 MB
• Storage type: NAND
• MTBF: Approximately 200'000 hours at 25C
• Tested ambient temperature: -40°C to 60°C
• IPsec hardware acceleration: Yes
• Wireless capabilities Wireless 2.4 GHz Max data rate: 300 Mbit/s
• Wireless 2.4 GHz number of chains: 2
• Wireless 2.4 GHz standards: 802.11b/g/n
• Antenna gain dBi for 2.4 GHz: 3.5
• Wireless 2.4 GHz chip model: IPQ-4019
• Wireless 2.4 GHz generation: Wi-Fi 4
• Wireless 5 GHz Max data rate: 867 Mbit/s
• Wireless 5 GHz number of chains: 2
• Wireless 5 GHz standards: 802.11a/n/ac
• Antenna gain dBi for 5 GHz: 4.5
• Wireless 5 GHz chip model: IPQ-4019
• Wireless 5 GHz generation: Wi-Fi 5
• Wireless 5 GHz Max data rate: 1733 Mbit/s
• Wireless 5 GHz number of chains: 4
INTENDED USE / APPLICATIONS
• Professional networking and communications deployments
• Commercial, institutional, or industrial installations
• Use with compatible equipment according to manufacturer specifications
Specifications
Technical specifications
| General | |
|---|---|
| Product Code | RBD25G-5HPacQD2HPnD |
| Brand | MikroTik |
| Model | Audience (Tri-band) |
| Operating System | RouterOS |
| RouterOS License | 4 |
| Physical | |
| Dimensions | 100 x 235 x 97 mm |
| Wireless / RF | |
| Wireless Type | Tri-band (one 2.4 GHz & two 5 GHz) |
| 2.4 GHz Standards | 802.11b/g/n |
| 2.4 GHz Generation | Wi-Fi 4 |
| 2.4 GHz Max Data Rate | 300 Mbit/s |
| 2.4 GHz Chains | 2 |
| 2.4 GHz Antenna Gain | 3.5 dBi |
| 2.4 GHz Chip Model | IPQ-4019 |
| 5 GHz Standards | 802.11a/n/ac |
| 5 GHz Generation | Wi-Fi 5 |
| 5 GHz Max Data Rate | 1733 Mbit/s |
| 5 GHz Chains | 4 |
| 5 GHz Antenna Gain | 4.5 dBi |
| 5 GHz Chip Model | IPQ-4019 |
| Compatibility | |
| CPU | IPQ-4019 |
| CPU Architecture | ARM 32bit |
| CPU Core Count | 4 |
| CPU Nominal Frequency | 716 MHz |
| Switch Chip Model | IPQ-4019 |
| RAM | 256 MB |
| Storage | 128 MB NAND |
| Environmental | |
| MTBF | Approximately 200,000 hours at 25°C |
| Tested Ambient Temperature | -40°C to 60°C |
| Networking & Connectivity | |
| IPsec Hardware Acceleration | Yes |
