Seco-Larm E-941SA-300 300lb Electromagnetic Lock

Seco-Larm · Intrusion & Alarm

Seco-Larm E-941SA-300 300-lb Indoor/Outdoor Electromagnetic Lock, 12 VDC, IP67

Part number / SKU
E-941SA-300
  • IP67 waterproof
$99.00

In stock

Warranty
Manufacturer warranty

Need project or contract pricing?

Request project pricing

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The Seco-Larm E-941SA-300 is a 300-lb (136 kg) electromagnetic lock for indoor and outdoor doors. It runs on 12 VDC, has no residual magnetism, and has MOV surge protection, so it releases cleanly when power is removed by the access control system.

The housing is stainless steel and the lock is waterproof to IP67 for outdoor use. It draws 315 mA at 12 VDC and operates from 14 to 131 F (-10 to 55 C). An adjustable mounting bracket, complete mounting hardware for typical installations and a pre-installed 36 in (91 cm) hookup wire are included. The electromagnet measures 6-3/4 x 1 x 1-1/4 in and the lock weighs 2 lb 13.5 oz.

  • Best for: indoor and outdoor doors that call for a 300-lb electromagnetic lock on 12 VDC.
  • System fit: access control systems that supply and switch 12 VDC lock power.
  • Important to know: the lock is 12 VDC only (plus or minus 10 percent); it is not a 24 VDC model.

Why teams choose it

Built for secure sites

  • Outdoor rated

    waterproof to IP67 with a stainless steel housing.

  • Clean release

    no residual magnetism when power is removed.

  • Low draw

    315 mA at 12 VDC.

  • Ready to wire

    pre-installed 36 in (91 cm) hookup wire and an adjustable mounting bracket are included.

Specifications

Technical specifications

General
Brand Seco-Larm
Model E-941SA-300
Device Type Electromagnetic lock
Holding Force 300 lb (136 kg)
Residual Magnetism None
Surge Protection MOV
Included Items Adjustable mounting bracket, mounting hardware for typical installations, pre-installed 36 in (91 cm) hookup wire
Electrical
Operating Voltage 12 VDC, plus or minus 10%
Current Draw 315 mA at 12 VDC
Physical
Housing Stainless steel
Electromagnet Dimensions 6-3/4 x 1 x 1-1/4 in (170 x 23 x 32 mm)
Armature Dimensions 6 x 3/8 x 1-1/4 in (152 x 10 x 32 mm)
Weight 2 lb 13.5 oz (1.29 kg)
Case Quantity 10 pcs
Environmental
IP Rating IP67 waterproof
Operating Temperature 14 to 131 F (-10 to 55 C)
Listings and Approvals
Agency Approvals CE
RoHS Compliant
