Tycon ENC-AL-65x18x20 Sealed Aluminum Enclosure Weatherproof Vented Lockable
- EhubAmerica SKU
- ENC-AL-65x18x20
$1,377.90
In stock
- Warranty
- Manufacturer warranty
Need project or contract pricing?
Request project pricing- Help in English, Spanish and Portuguese
- 30-day returns
Not sure it fits your system? Check compatibility
Overview
What it is and who it is for
PRODUCT OVERVIEW
Tycon ENC-AL-65x18x20 Sealed Hinged Aluminum Enclosure
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
PRODUCT TYPE
Batteries
KEY FEATURES
- Weatherproof, UV Resistant, Outdoor Enclosure
- Double Keyed Locking System
- Diamond Plate Aluminum
- Rubber Gasket Nipple Hinged Top
- Dual Screened Weatherproof Vents
- Heavy Duty Bottom Standoffs
- Welded Security Shackle to Chain Lock in Place
- Battery enclosure
- Backup Power Systems
- Equipment enclosure
- Equipment security
- Enclosure External Size: 69” x 20.5” x 25” (1750 x 520 x 640mm)
- Internal Dimensions: 64.5” x 17.5” x 19.5” (1638 x 444 x 495mm)
- Net Weight: 59.5 lbs. (27kg)
- Type: Vented Enclosure
- Weatherproofing: IP65
- Material: 2.0 mm Aluminum checker plated
- Material Struts: 3.0 mm Aluminum Flat Plate
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
TECHNICAL SPECIFICATIONS
- Brand: Tycon
- Model: ENC-AL-65x18x20
- Product Type: Batteries
- Weatherproof, UV Resistant, Outdoor Enclosure
- Double Keyed Locking System
- Diamond Plate Aluminum
- Rubber Gasket Nipple Hinged Top
- Dual Screened Weatherproof Vents
- Heavy Duty Bottom Standoffs
- Welded Security Shackle to Chain Lock in Place
- Battery enclosure
- Backup Power Systems
- Equipment enclosure
- Equipment security
- Enclosure External Size: 69” x 20.5” x 25” (1750 x 520 x 640mm)
- Internal Dimensions: 64.5” x 17.5” x 19.5” (1638 x 444 x 495mm)
- Net Weight: 59.5 lbs. (27kg)
- Type: Vented Enclosure
- Weatherproofing: IP65
- Material: 2.0 mm Aluminum checker plated
- Material Struts: 3.0 mm Aluminum Flat Plate
- Material Back Rack: 4.0mm Aluminum Flat Plate
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
INTENDED USE / APPLICATIONS
Designed for backup, off-grid, remote equipment, telecommunications, surveillance, and network power applications.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
Specifications
Technical specifications
| General | |
|---|---|
| Brand | Tycon Power Systems |
| Model/Part Number | ENC-AL-65x18x20 |
| Type | Vented Sealed Aluminum Enclosure |
| Material | 2.0 mm Aluminum checker plated |
| Material Struts | 3.0 mm Aluminum Flat Plate |
| Material Back Rack | 4.0 mm Aluminum Flat Plate |
| Physical | |
| External Dimensions | 69" × 20.5" × 25" (1750 × 520 × 640 mm) |
| Internal Dimensions | 64.5" × 17.5" × 19.5" (1638 × 444 × 495 mm) |
| Net Weight | 59.5 lbs (27 kg) |
| Back Panel Cable Gland Holes | 8× 20 mm holes |
| Included Cable Glands | 4× RJ45 Cable Glands and 4× Hole Plugs |
| Environmental | |
| Weatherproofing | IP65 |
| UV Resistant | Yes |
| Hinged Top Seal | Rubber Gasket Nipple |
| Ventilation | Dual Screened Weatherproof Vents |
| Fan | PowerVent 24/48 VDC 120 mm with 45°C Thermostat (mounted) |
| Compatibility | |
| Mounting | DIN Rails or metal plate mounting inside enclosure |
| Security | Welded security shackle for chain lock; double keyed locking system |
