Tycon TPBAT12-180 12V 180Ah Pure Lead Carbon AGM Battery

EhubAmerica SKU
TPBAT12-180
$1,016.49

In stock

Warranty
Manufacturer warranty

Need project or contract pricing?

Request project pricing

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

PRODUCT OVERVIEW

The TPBAT12-180 high rate valve regulated pure lead carbon sealed lead acid (VRLA) AGM battery has been developed for long term operation in harsh environments . They have a very high deep discharge cycle life and impressive 8 year float life . They are designed to operate over a wide temperature range such as those experienced in outdoor equipment applications . The batteries can be installed in any position without affecting their performance or reliability.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

PRODUCT TYPE

Batteries

KEY FEATURES

  • Sealed and Maintenance Free Pure Lead Carbon
  • Safety Valve for Ultimate Safety; Prevents Overpressure
  • Exceptional Deep Discharge Recovery Performance
  • Low Self Discharge Characteristics
  • Highly Resistant to Vibration and Shock
  • Remote Equipment Power
  • Surveillance Cameras
  • Wireless Base Stations
  • Medical Equipment
  • Remote Sensors
  • Backup Power Systems
  • 559 x 125 x 320 (22 x 4.92 x 12.6”)
  • 57.6kg (127lb)
  • Voltage: 12V
  • Capacity (amp hours; 20hr): 180
  • Typical Float Life: 8 Years
  • 30% Discharge Cycle Life: 5000 Cycles
  • Type / Technology: Valve Regulated Pure Lead Carbon Sealed Lead Acid / Absorbent Glass Mat (AGM)

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

TECHNICAL SPECIFICATIONS

  • Brand: Tycon
  • Model: TPBAT12-180
  • Product Type: Batteries
  • Sealed and Maintenance Free Pure Lead Carbon
  • Safety Valve for Ultimate Safety; Prevents Overpressure
  • Exceptional Deep Discharge Recovery Performance
  • Low Self Discharge Characteristics
  • Highly Resistant to Vibration and Shock
  • Remote Equipment Power
  • Surveillance Cameras
  • Wireless Base Stations
  • Medical Equipment
  • Remote Sensors
  • Backup Power Systems
  • 559 x 125 x 320 (22 x 4.92 x 12.6”)
  • 57.6kg (127lb)
  • Voltage: 12V
  • Capacity (amp hours; 20hr): 180
  • Typical Float Life: 8 Years
  • 30% Discharge Cycle Life: 5000 Cycles
  • Type / Technology: Valve Regulated Pure Lead Carbon Sealed Lead Acid / Absorbent Glass Mat (AGM)
  • Self-Discharge (25°C): <5% per month
  • Charge Voltage (-3mV / °C): 14.1 to14.4V ; Max Current 180A
  • Float Voltage (-2mV / °C): 13.5 to 13.8V
  • Internal Resistance: 3.5 mOhms
  • Operating Temperature: -40C (-40F) to +55C (131F)
  • Housing: ABS (UL94V-0)
  • Certifications: ISO 9001: 2000, ISO 14001, OHSAS 18001, IATF16949
  • Compliances: IEC 60896

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

INTENDED USE / APPLICATIONS

Designed for backup, off-grid, remote equipment, telecommunications, surveillance, and network power applications.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

Specifications

Technical specifications

TYCON TPBAT12-180 TECHNICAL SPECIFICATIONS
General
Model TPBAT12-180
Brand Tycon Power Systems
Type Valve Regulated Pure Lead Carbon Sealed Lead Acid (VRLA) / Absorbent Glass Mat (AGM)
Housing Material ABS (UL94V-0)
Physical
Dimensions (L × W × H) 559 × 125 × 320 mm (22 × 4.92 × 12.6 in)
Weight 57.6 kg (127 lb)
Power & Electrical
Voltage 12V
Capacity (20-hour rate) 180 Ah
Charge Voltage 14.1 to 14.4V at -3mV/°C; Max Charge Current 180A
Float Voltage 13.5 to 13.8V at -2mV/°C
Internal Resistance 3.5 mOhms
Float Life 8 years typical
30% Depth of Discharge Cycle Life 5,000 cycles
Self-Discharge (25°C) <5% per month
Environmental
Operating Temperature Range -40°C (-40°F) to +55°C (131°F)
Compatibility
Certifications ISO 9001:2000, ISO 14001, OHSAS 18001, IATF16949
Compliance Standard IEC 60896
