Ubiquiti LBE-5AC-Gen2-US LiteBeam 5AC Gen2 23dBi 450Mbps Point-to-Point
- EhubAmerica SKU
- LBE-5AC-Gen2-US
- 2X2
- Passive PoE (Pairs 4,5+;7,8 Return)
Special order· Lead time confirmed by our team after you order.
- Warranty
- Manufacturer warranty
Need project or contract pricing?
Request project pricing- Help in English, Spanish and Portuguese
- 30-day returns
Not sure it fits your system? Check compatibility
Overview
What it is and who it is for
PRODUCT OVERVIEW
Ubiquiti LiteBeam ac Gen LBE-5AC-Gen2-US 2X2 MIMO airMAX Wireless Antenna 5GHz 23dBi 450+ Mbps CPE
PRODUCT TYPE
Point-to-Point
KEY FEATURES
• Ubiquiti LiteBeam ac Gen LBE-5AC-Gen2-US 2X2 MIMO airMAX Wireless Antenna 5GHz 23dBi 450+ Mbps CPE
• Improved Radio Design: Enhanced performance and signal strength.
• Improved Mounting: Flexible mounting options for easy installation.
• Improved Surge Protection: Increased durability against electrical surges.
• Management WiFi Radio: Dedicated for easy setup and management via the UISP Mobile App.
• AirOS 8: Advanced operating system for improved user experience and performance.
• UISP Mobile App: Available for both Android and iOS for convenient management.
• Ideal for point-to-point (PtP) and point-to-multipoint (PtMP) wireless networking in a variety of environments, including residential, commercial, and industrial settings.
• 358 x 271.95 x 272.5 mm (14.09 x 10.71 x 10.73')
• Without Mount: 800 g (1.76 lbs)
• With Mount: 980 g (2.16 lbs)
• International version LBE-5AC-Gen2
• Dimensions: 358 x 271.95 x 272.5mm (14.09 x 10.71 x 10.73")
• Weight: Without Mount: 800g (1.76lbs)
• With Mount: 980g (2.16lbs)
• Power Supply: 24V, 0.3A Gigabit PoE Adapter (included)
• Max. Power Consumption: 7W
• Power Method: Passive PoE (Pairs 4,5+;7,8 Return)
TECHNICAL SPECIFICATIONS
• Brand: Ubiquiti
• Model: LBE-5AC-Gen2-US
• Product Type: Point-to-Point
• Ubiquiti LiteBeam ac Gen LBE-5AC-Gen2-US 2X2 MIMO airMAX Wireless Antenna 5GHz 23dBi 450+ Mbps CPE
• Improved Radio Design: Enhanced performance and signal strength.
• Improved Mounting: Flexible mounting options for easy installation.
• Improved Surge Protection: Increased durability against electrical surges.
• Management WiFi Radio: Dedicated for easy setup and management via the UISP Mobile App.
• AirOS 8: Advanced operating system for improved user experience and performance.
• UISP Mobile App: Available for both Android and iOS for convenient management.
• Ideal for point-to-point (PtP) and point-to-multipoint (PtMP) wireless networking in a variety of environments, including residential, commercial, and industrial settings.
• 358 x 271.95 x 272.5 mm (14.09 x 10.71 x 10.73')
• Without Mount: 800 g (1.76 lbs)
• With Mount: 980 g (2.16 lbs)
• International version LBE-5AC-Gen2
• Dimensions: 358 x 271.95 x 272.5mm (14.09 x 10.71 x 10.73")
• Weight: Without Mount: 800g (1.76lbs)
• With Mount: 980g (2.16lbs)
• Power Supply: 24V, 0.3A Gigabit PoE Adapter (included)
• Max. Power Consumption: 7W
• Power Method: Passive PoE (Pairs 4,5+;7,8 Return)
• Supported Voltage Range: 24V±10%
• Operating Frequency: 5150 - 5250 MHz
• Gain: 23dBi
• Networking Interface: (1) 10/100/1000 Ethernet Port
• Processor Specs: MIPS 74Kc
• Memory: 64 MB DDR2
• LEDs: Power, Ethernet
• Channel Sizes: PtP Mode: 10/20/30/40/50/60/80MHz
• PtMP Mode: 10/20/30/40MHz
• Enclosure Characteristics: Reflector (SGCC 0.6T) / Plastic: PC
• Mounting: Pole-Mounting Kit (Included)
INTENDED USE / APPLICATIONS
• Professional networking and communications deployments
• Commercial, institutional, or industrial installations
• Use with compatible equipment according to manufacturer specifications
Specifications
Technical specifications
| General | |
|---|---|
| Model | LBE-5AC-Gen2-US |
| Product Name | LiteBeam 5AC Gen 2 (US Version) |
| Type | airMAX ac CPE |
| MIMO Configuration | 2X2 |
| Operating Frequency | 5150 - 5250 MHz |
| Gain | 23dBi |
| Throughput | 450+ Mbps |
| Physical | |
| Dimensions | 358 x 271.95 x 272.5 mm (14.09 x 10.71 x 10.73 in) |
| Weight (Without Mount) | 800 g (1.76 lbs) |
| Weight (With Mount) | 980 g (2.16 lbs) |
| Enclosure Material | Reflector (SGCC 0.6T) / Plastic (PC) |
| Mounting Type | Pole-Mounting |
| Power & Electrical | |
| Power Supply | 24V, 0.3A Gigabit PoE Adapter (included) |
| Max. Power Consumption | 7W |
| Power Method | Passive PoE (Pairs 4,5+;7,8 Return) |
| Supported Voltage Range | 24V ±10% |
| Wireless / RF | |
| Channel Sizes (PtP Mode) | 10/20/30/40/50/60/80 MHz |
| Channel Sizes (PtMP Mode) | 10/20/30/40 MHz |
| Networking & Connectivity | |
| Ethernet Interface | (1) 10/100/1000 Gigabit Ethernet Port |
| Processor | MIPS 74Kc |
| Memory | 64 MB DDR2 |
| LEDs | Power, Ethernet |
| Compatibility | |
| Compatible Models | LBE-5AC-Gen2 (International version) |
