Ubiquiti · Networking Accessories
Ubiquiti mFI-mPort-S Machine-to-Machine M2M Control Hub
- EhubAmerica SKU
- mFI-mPort-S
- 802.11b/g/n
- (1) 10/100 Ethernet Port
In stock
- Warranty
- Manufacturer warranty
Need project or contract pricing?
Request project pricing- Help in English, Spanish and Portuguese
- 30-day returns
Not sure it fits your system? Check compatibility
Overview
What it is and who it is for
PRODUCT OVERVIEW
Ubiquiti mPort-S networked serial interface for the mFi machine-to-machine platform, featuring RS232/RS422/RS485 connectivity, 10/100 Ethernet, 802.11b/g/n Wi-Fi, and integration with mFi Controller software.
PRODUCT TYPE
Networking Accessories
KEY FEATURES
• Designed for the Ubiquiti mFi machine-to-machine management platform
• RS232, RS422, and RS485 serial protocol support
• (1) DB9 serial port
• (1) terminal block serial port
• (1) 10/100 Ethernet network interface
• Built-in 802.11b/g/n Wi-Fi connectivity
• Internal and external antenna support
• Designed for management through mFi Controller software
• mFi Controller supports device auto-detection and provisioning
• Supports user-defined automation rules through the mFi platform
• Supports event recording and alerts through mFi Controller
• Remote terminal functionality supported through mFi Controller
• Wall-mountable design
• Integrated PoE adapter specified by manufacturer
TECHNICAL SPECIFICATIONS
• Brand: Ubiquiti
• Model: mFI-mPort-S
• Product Type: Networking Accessories
• Manufacturer: Ubiquiti Networks
• Model: mPort-S
• Dimensions Without Bracket: 100 x 60 x 27.5 mm (3.94 x 2.36 x 1.08 in)
• Dimensions With Bracket: 100 x 60 x 36.5 mm (3.94 x 2.36 x 1.44 in)
• Weight With Bracket: 119 g (4.2 oz)
• Power Supply: 24V, 0.5A with surge protection
• Maximum Power Consumption: 3W
• Networking Interface: (1) 10/100 Ethernet port
• Serial Ports: (1) DB9 serial port; (1) terminal block serial port
• Serial Protocols: RS232, RS422, RS485
• Wi-Fi Standards: 802.11b/g/n
• Antenna: Internal and external
• Output Power: 18 dBm
• Memory: 16 MB RAM, 8 MB Flash
• LEDs: (3) Power, Ethernet, Status
• Mounting: Wall-mount bracket
• Operating Temperature: -10°C to 70°C (14°F to 158°F)
• Operating Humidity: 5% to 80% noncondensing
• Manufacturer specifications for the mPort-S are provided on page 10 of the supplied mFi Machine-to-Machine Management System .
INTENDED USE / APPLICATIONS
• Connecting serial devices to an mFi machine network
• Machine-to-machine management and monitoring
• Automated machine control through mFi Controller software
• Sensor data collection and analytics
• Remote monitoring and control of compatible connected equipment
• Integration of compatible third-party devices into an mFi system
Specifications
Technical specifications
| General | |
|---|---|
| Brand | Ubiquiti |
| Model | mFI-mPort-S |
| Product Type | Machine-to-Machine (M2M) Control Hub |
| Physical | |
| Dimensions | 100 x 60 x 27.5 mm (3.94 x 2.36 x 1.08 in) |
| Weight | 119 g (4.2 oz) |
| Mounting | Wall-mount bracket (Included) |
| Power & Electrical | |
| Power Supply | 24V, 0.5A |
| Surge Protection | Integrated |
| PoE Adapter | Included |
| Networking & Connectivity | |
| Ethernet Ports | (1) 10/100 Ethernet Port |
| Serial Ports | (1) DB9 Serial Port, (1) Terminal Block Serial Port |
| Wi-Fi Standards | 802.11b/g/n |
| Memory | 16 MB RAM, 8 MB Flash |
| Environmental | |
| Operating Temperature | -10 to 70°C (14 to 158°F) |
| Operating Humidity | 5 to 80% Non-condensing |
