Ubiquiti U7-PRO-MAX WiFi 7 Access Point 8 Spatial Streams 6GHz PoE+
- EhubAmerica SKU
- U7-PRO-MAX
- PoE+
In stock
- Warranty
- Manufacturer warranty
Need project or contract pricing?
Request project pricing- Help in English, Spanish and Portuguese
- 30-day returns
Not sure it fits your system? Check compatibility
Overview
What it is and who it is for
PRODUCT OVERVIEW
Ubiquiti ceiling-mounted WiFi 7 access point with 8 spatial streams, 6 GHz support, 2.5 GbE uplink, PoE+ power, spectral radio, coverage up to 160 m², and support for 500+ clients.
PRODUCT TYPE
Wireless Access Points
KEY FEATURES
• WiFi 7 with 6 GHz support
• 8 spatial streams
• Spectral radio for real-time spectral analysis and dynamic channel optimization
• Coverage up to 160 m² (1,750 ft²)
• Supports 500+ concurrent clients
• (1) 1/2.5 GbE RJ45 networking interface
• PoE+ powered
• 2x2 DL/UL MU-MIMO at 2.4 GHz
• 4x4 DL/UL MU-MIMO at 5 GHz
• 2x2 DL/UL MU-MIMO at 6 GHz
• Up to 8.6 Gbps data rate at 5 GHz
• Up to 5.7 Gbps data rate at 6 GHz
• Wall or ceiling mounting
• 6 GHz operation is supported in certain countries
• Multi-Link Operation capability via future software update
TECHNICAL SPECIFICATIONS
• Manufacturer: Ubiquiti
• Part Number: U7-PRO-MAX
• WiFi Standards: 802.11a/b/g/n/ac/ax/be (WiFi 6/6E/7)
• Spatial Streams: 8
• Networking Interface: (1) 1/2.5 GbE RJ45
• Power Method: PoE+
• Power Supply: UniFi PoE Switch
• Maximum Power Consumption: 25 W
• Dimensions: Ø206 x 46 mm (Ø8.1 x 1.8")
• Weight: 680 g (1.5 lb)
• Enclosure Material: Polycarbonate, aluminum
• Mount Material: Stainless steel (SUS304), galvanized steel (SGCC)
• Mounting Options: Wall, ceiling
• Mount: Included
• 2.4 GHz MIMO: 2x2 DL/UL MU-MIMO
• 5 GHz MIMO: 4x4 DL/UL MU-MIMO
• 6 GHz MIMO: 2x2 DL/UL MU-MIMO
• Maximum 2.4 GHz Data Rate: 688 Mbps (BW40)
• Maximum 5 GHz Data Rate: 8.6 Gbps (BW240)
• Maximum 6 GHz Data Rate: 5.7 Gbps (BW320)
• 2.4 GHz Antenna Gain: 4 dBi
• 5 GHz Antenna Gain: 6 dBi
• 6 GHz Antenna Gain: 5.9 dBi
• Maximum 2.4 GHz TX Power: 23 dBm
• Maximum 5 GHz TX Power: 29 dBm
• Maximum 6 GHz TX Power: 23 dBm
• Wireless Security: WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK)
• BSSID: 8 per Radio
• VLAN Support: 802.1Q
• Advanced QoS: Per-User Rate Limiting
• Concurrent Clients: 500+
• Operating Temperature: -30 to 50°C (-22 to 122°F)
• Operating Humidity: 5 to 95% Noncondensing
• Certifications: CE, FCC, IC
• UniFi Network Requirement: Version 8.2.93 and Later
INTENDED USE / APPLICATIONS
• Enterprise-grade wireless networking
• High-density office environments
• Retail centers
• Public spaces
• Deployments requiring high-speed, stable wireless connectivity
Specifications
Technical specifications
| General | |
|---|---|
| Model | U7-PRO-MAX |
| Brand | Ubiquiti |
| Product Type | Ceiling-Mounted WiFi 7 Access Point |
| Spatial Streams | 8 |
| Coverage Area | 160 m² (1,750 ft²) |
| Max Connected Devices | 500+ |
| Physical | |
| Dimensions | Ø206 x 46 mm (Ø8.1 x 1.8") |
| Weight | 680 g (1.5 lb) |
| Enclosure Material | Polycarbonate, aluminum |
| Mount Material | Stainless steel (SUS304), galvanized steel (SGCC) |
| Mounting Options | Wall, ceiling (included) |
| Power & Electrical | |
| Power Method | PoE+ |
| Power Supply | UniFi PoE switch |
| Max Power Consumption | 25W |
| Max TX Power (2.4 GHz) | 23 dBm |
| Max TX Power (5 GHz) | 29 dBm |
| Wireless / RF | |
| WiFi Standard | WiFi 7 |
| 6 GHz Support | Yes (supported in certain countries) |
| Technology | MU-MIMO, Spectral Radio (real-time spectral analysis) |
| Networking & Connectivity | |
| Uplink Port | (1) 1/2.5 GbE RJ45 port |
| Uplink Speed | 2.5 GbE |
| Compatibility | |
