Ubiquiti U7-Pro-XGS-B-US WiFi 7 Access Point 8-Stream 10GbE Tri-Band

PRODUCT OVERVIEW

Ubiquiti U7-Pro-XGS-B-US UniFi WiFi 7 Access Point Black with 10GbE

PRODUCT TYPE / CATEGORY

• Networking
• Wireless Access Points

KEY FEATURES

• UniFi WiFi 7 access point in black finish
• Tri-band operation: 2.4 GHz, 5 GHz, and 6 GHz
• 8 spatial streams for high-density wireless performance
• 10 GbE RJ45 uplink support
• Dedicated spectral scanning radio for RF analysis
• Supports 320 MHz channel bandwidth on WiFi 7
• PoE++ powered installation
• Ceiling-mounted design for professional indoor deployments
• UV-stabilized polycarbonate and aluminum alloy enclosure
• Managed through UniFi Network
• NDAA compliant
• Next-Generation WiFi 7 Performance
• The U7 Pro XGS is designed for networks that need high wireless capacity and low latency. With WiFi 7 support, 6 GHz operation, and wide channel bandwidths up to 320 MHz, this access point is ideal for bandwidth-heavy environments such as offices, classrooms, meeting rooms, hotels, retail spaces, and advanced home networks.
• 10GbE Wired Uplink
• A single 10GbE RJ45 port provides high-speed wired connectivity and supports 10G, 5G, 2.5G, and 1G Ethernet speeds. This makes the U7-Pro-XGS-B-US a strong fit for multi-gig switching environments where WiFi 7 performance needs a wired backbone that can actually keep up.
• Dedicated Spectral Scanning Radio
• The integrated spectral scanning radio allows the access point to analyze the RF environment without relying only on client-serving radios. This helps improve channel planning, reduce interference, and maintain stable wireless performance in dense or noisy environments.
• Ideal Applications

TECHNICAL SPECIFICATIONS

• Brand: Ubiquiti
• Model: U7-Pro-XGS-B-US
• Product Type: Wireless Access Points
• UniFi WiFi 7 access point in black finish
• Tri-band operation: 2.4 GHz, 5 GHz, and 6 GHz
• 8 spatial streams for high-density wireless performance
• 10 GbE RJ45 uplink support
• Dedicated spectral scanning radio for RF analysis
• Supports 320 MHz channel bandwidth on WiFi 7
• PoE++ powered installation
• Ceiling-mounted design for professional indoor deployments
• UV-stabilized polycarbonate and aluminum alloy enclosure
• Managed through UniFi Network
• NDAA compliant
• Enterprise WiFi 7 deployments
• High-density office wireless networks
• Hotels, schools, and campus environments
• Retail and hospitality networks
• Multi-gig UniFi network upgrades
• 6 GHz wireless deployments
• Professional ceiling-mounted indoor installations
• Overview: Dimensions: Ø215 x 32.5 mm (Ø8.5 x 1.3')
• WiFi Standard: WiFi 7
• Spatial Streams: 8
• Coverage Area: 160 m² (1,750 ft²)
• Max. Client Count: 500+
• Uplink: 10 GbE
• Mounting: Ceiling, Wall (Lite Mount Included)
• Power Method: PoE++
• Performance: MIMO: 6 GHz: 2 x 2 (DL/UL MU-MIMO)
• 5 GHz: 4 x 4 (DL/UL MU-MIMO)
• 2.4 GHz: 2 x 2 (DL/UL MU-MIMO)

INTENDED USE / APPLICATIONS

• Outdoor or indoor wireless networking, as specified
• Point-to-point or point-to-multipoint deployments where compatible
• Professional network installations
