Ubiquiti UA-G3-Flex-B 1080p 2MP Mini Turret IP Camera PoE IR
- EhubAmerica SKU
- UA-G3-Flex-B
- 1080p, 2MP
$221.99
In stock
- Warranty
- Manufacturer warranty
Need project or contract pricing?
Request project pricing- Help in English, Spanish and Portuguese
- 30-day returns
Not sure it fits your system? Check compatibility
Overview
What it is and who it is for
PRODUCT OVERVIEW
Full HD (1080p) mini turret camera with infrared LEDs and versatile mounting options for indoor and outdoor installations.
PRODUCT TYPE
IP Camera
KEY FEATURES
- 87 viewing angle
- Microphone
- HD (2MP) 25 FPS
- IR LED 6m (20ft) IR night vision
- Status LED
- Desktop, wall, pole, hard-ceiling, conduits mounts*
- Weather-resistant IPX4-rated enclosure * Ceiling and conduit mounts sold separately
- Technical Specification:
- Overview: Dimensions: 84 x 84 x 40.8 mm (3.3 x 3.3 x 1.6')
- NFC Card & Keyfob Access
- PIN Access
- Touch Pass
- Mobile Unlock
- Weatherproofing: IP55
- Mechanical: Weight: 165 g (5.8 oz)
- Enclosure Material: Polycarbonate, glass, aluminium alloy
- Mount Material: Polycarbonate, aluminum alloy
- Mounting: Wall (Included)
TECHNICAL SPECIFICATIONS
- Brand: Ubiquiti
- Model: UA-G3-Flex-B
- Product Type: Security Cameras
- 87 viewing angle
- Microphone
- HD (2MP) 25 FPS
- IR LED 6m (20ft) IR night vision
- Status LED
- Desktop, wall, pole, hard-ceiling, conduits mounts*
- Weather-resistant IPX4-rated enclosure * Ceiling and conduit mounts sold separately
- Overview: Dimensions: 84 x 84 x 40.8 mm (3.3 x 3.3 x 1.6')
- NFC Card & Keyfob Access
- PIN Access
- Touch Pass
- Mobile Unlock
- Weatherproofing: IP55
- Mechanical: Weight: 165 g (5.8 oz)
- Enclosure Material: Polycarbonate, glass, aluminium alloy
- Mount Material: Polycarbonate, aluminum alloy
- Mounting: Wall (Included)
- Gang-box, junction box (Optional)
- Hardware: Indoor and Outdoor Use: Yes
- Ambient Operating Temperature: -30 to 60° C (-22 to 140° F)
- Ambient Operating Humidity: 5 to 90% noncondensing
- Networking Interface: (1) 10/100 MbE RJ45 port
- Connectivity: BLE 4.1
- NFC
- Power Method: PoE
- UL 294 Power-limited Class 2 PSU
- UL 60950-1/62368-1 LPS/PS2 PSU
- Max. Power Consumption: 5W
- Supported Voltage Range: 44—57V DC
INTENDED USE / APPLICATIONS
- Video surveillance and security monitoring
- Commercial, institutional, or industrial installations
- Integration with compatible network and recording systems
Specifications
Technical specifications
| TECHNICAL SPECIFICATIONS: Ubiquiti UA-G3-Flex-B | |
|---|---|
| General | |
| Model | UA-G3-Flex-B |
| Type | 1080p 2MP Mini Turret IP Camera |
| Resolution | 1080p, 2MP |
| Frame Rate | 25 FPS |
| Field of View | 87° |
| Physical | |
| Dimensions | 84 x 84 x 40.8 mm (3.3 x 3.3 x 1.6") |
| Weight | 165 g (5.8 oz) |
| Enclosure Material | Polycarbonate, glass, aluminium alloy |
| Mount Material | Polycarbonate, aluminum alloy |
| Mounting Options | Wall (included), gang-box, junction box (optional) |
| Indoor/Outdoor Use | Yes |
| Power & Electrical | |
| Power Method | PoE |
| Max. Power Consumption | 5W |
| Supported Voltage Range | 44–57V DC |
| Power Standards | UL 294 Power-limited Class 2 PSU, UL 60950-1/62368-1 LPS/PS2 PSU |
| ESD/EMP Protection (Air) | ±15kV |
| ESD/EMP Protection (Contact) | ±8kV |
| Camera & Imaging | |
| IR Night Vision | 6m (20ft) range with LED |
| Networking & Connectivity | |
| Network Interface | (1) 10/100 Mbps RJ45 port |
| Bluetooth | BLE 4.1 |
| NFC | 13.56 MHz, read range < 30 mm (1.18") |
| NFC Technology | ISO/IEC 14443A/14443B/15693/18092 (Ecma 340), MIFARE Classic/MIFARE DESFIRE, Sony FeliCa™ (ID only), NFC Forum tags T1T/T2T/T3T/T4T/T5T, ECP 2.0 |
| Audio | |
| Microphone | Yes |
| Speaker | Yes |
| Environmental | |
| Weatherproofing | IP55 |
| Ambient Operating Temperature | -30 to 60°C (-22 to 140°F) |
| Ambient Operating Humidity | 5 to 90% noncondensing |
| Compatibility | |
| Certifications | CE, FCC, IC, UL 294, CAN/ULC-60839-11-1 |
