Ubiquiti UDR7-US UniFi Dream Router 7 WiFi 7 10G Cloud Gateway with PoE Switch

PRODUCT OVERVIEW

Ubiquiti UDR7-US UniFi Dream Router 7 WiFi 7 10G Cloud Gateway

PRODUCT TYPE / CATEGORY

• Networking
• Security Cameras

KEY FEATURES

• Desktop 10G UniFi Cloud Gateway
• Integrated tri-band WiFi 7 access point
• 10G SFP+ WAN port for fiber or high-speed uplink
• 2.5 GbE RJ45 WAN port
• 3 x 2.5 GbE RJ45 LAN ports
• 1 x PoE LAN port for powering compatible devices
• Up to 2.3 Gbps IDS/IPS gateway throughput
• Supports 300+ connected client devices
• microSD expansion slot for UniFi applications
• 0.96-inch status display
• Quad-core ARM Cortex-A53 processor at 1.5 GHz
• 3 GB system memory
• Runs UniFi Network and full UniFi application support
• Universal AC input with internal power supply
• All-in-One UniFi Gateway
• The UDR7 brings multiple UniFi functions into one compact device, including routing, firewall security, WiFi 7, switching, and UniFi application hosting. This reduces the need for separate gateway, access point, switch, and controller hardware, which is helpful unless your hobby is collecting power adapters like cursed trophies.
• WiFi 7 Performance with 6 GHz Support
• Integrated WiFi 7 provides faster wireless speeds, lower latency, improved efficiency, and support for newer 6 GHz-capable devices. The Dream Router 7 is built for modern wireless environments with streaming, cloud applications, video calls, smart devices, and high-density client usage.

TECHNICAL SPECIFICATIONS

• Brand: Ubiquiti
• Model: UDR7-US
• Product Type: Security Cameras
• Hardware Product Model: UDR7-US
• Product Name: UniFi Dream Router 7
• Device Type: Desktop 10G Cloud Gateway with integrated WiFi 7
• Processor: Quad-core ARM Cortex-A53 at 1.5 GHz
• System Memory: 3 GB
• Enclosure Material: Polycarbonate
• Weight: 1.1 kg (2.4 lb)
• Display: 0.96-inch status display
• Management: Ethernet and Bluetooth
• Button: Factory reset
• Networking Interfaces WAN Ports: 1 x 10G SFP+ WAN port
• 1 x 2.5 GbE RJ45 WAN port
• LAN Ports: 3 x 2.5 GbE RJ45 LAN ports
• PoE Output: 1 x PoE LAN port
• Storage Expansion: microSD expansion slot
• Wireless Wireless Standard: WiFi 7 / 802.11be
• Frequency Bands: 2.4 GHz, 5 GHz, and 6 GHz
• 2.4 GHz Throughput: Up to 688 Mbps
• 5 GHz Throughput: Up to 4.3 Gbps
• 6 GHz Throughput: Up to 5.7 Gbps
• Client Capacity: 300+ connected clients
• Gateway Performance IDS/IPS Throughput: Up to 2.3 Gbps
• Security Features: Stateful firewall, application-aware firewall, DPI, IDS/IPS, content filtering, ad blocking, and VLAN/subnet segmentation
• VPN Support: WireGuard, OpenVPN, IPsec, L2TP, Teleport, and Site Magic
• Networking Features: Multi-WAN, load balancing, policy-based WAN/VPN routing, DHCP server, IPv6 ISP support, mDNS, IGMP proxy, and advanced QoS
• Power Power Method: Universal AC input
• Supported Voltage Range: 100–240V AC
• Power Supply: Internal 50W AC/DC power supply
• Power Consumption: 26W excluding PoE output

INTENDED USE / APPLICATIONS

• Video surveillance and security monitoring
• Commercial, institutional, or industrial installations
• Integration with compatible network and recording systems
