Ubiquiti US-48-500W Switch PoE Switch Managed PoE+ Gigabit with SFP (500W)

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐈𝐓𝐋𝐄
Ubiquiti US-48-500W UniFi 48-Port Managed Gigabit PoE+ Switch 2 SFP+ 2 SFP 500W

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐎𝐕𝐄𝐑𝐕𝐈𝐄𝐖
Ubiquiti US-48-500W fully managed UniFi PoE+ switch with 48 Gigabit RJ45 ports, two 10G SFP+ and two 1G SFP ports, 500W power supply, 70 Gbps non-blocking throughput, and IEEE 802.3af/at PoE support.

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐘𝐏𝐄 / 𝐂𝐀𝐓𝐄𝐆𝐎𝐑𝐘
Networking
Routers and Switches

𝐊𝐄𝐘 𝐅𝐄𝐀𝐓𝐔𝐑𝐄𝐒

• (48) 10/100/1000 Mbps Gigabit Ethernet RJ45 ports
• (2) 1/10 Gbps SFP+ ports
• (2) 1 Gbps SFP ports
• (1) RJ45 serial console port
• Auto-sensing IEEE 802.3af/at PoE+
• Configurable 24V passive PoE
• Maximum PoE+ output of 34.2W per port by PSE
• 500W internal AC/DC power supply
• 70 Gbps total non-blocking throughput
• 140 Gbps switching capacity
• 104.16 Mpps forwarding rate
• Ethernet in-band management
• RJ45 serial out-of-band management
• Rack-mountable design
• UniFi Controller management
• Per-port PoE configuration
• Network and VLAN configuration
• Port mirroring and port aggregation support
• RSTP and Spanning Tree Protocol support
• SNMP support
• 9216-byte jumbo frame support
• 802.1X RADIUS authentication and dynamic VLAN support

𝐓𝐄𝐂𝐇𝐍𝐈𝐂𝐀𝐋 𝐒𝐏𝐄𝐂𝐈𝐅𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒

• Manufacturer: Ubiquiti
• Model / Part Number: US-48-500W
• Product Family: UniFi Switch
• Networking Interfaces: (48) 10/100/1000 Mbps RJ45 Ethernet ports
• SFP+ Interfaces: (2) 1/10 Gbps SFP+ Ethernet ports
• SFP Interfaces: (2) 1 Gbps SFP Ethernet ports
• Management Interface: (1) RJ45 serial port out-of-band, Ethernet in-band
• Total Non-Blocking Throughput: 70 Gbps
• Switching Capacity: 140 Gbps
• Forwarding Rate: 104.16 Mpps
• MAC Address Table: 16,384
• Maximum Aggregations: 6
• Monitoring Sessions: 1
• Maximum VLANs: 255
• PoE Interfaces: IEEE 802.3af/at PoE+ and 24V DC passive PoE
• Maximum PoE+ Wattage per Port by PSE: 34.2W
• IEEE 802.3at Voltage Range: 50–57V
• Maximum Passive PoE Wattage per Port: 17W
• 24V Passive PoE Voltage Range: 20–27V
• Power Method: 100–240V AC, 50/60 Hz universal input
• Power Supply: Internal AC/DC, 500W DC
• Maximum Power Consumption Including PoE Output: 500W
• Maximum Power Consumption Excluding PoE Output: 64W
• RJ45 Port LEDs: PoE, speed, link, activity
• SFP Port LEDs: Speed, link, activity
• Dimensions: 485 x 43.7 x 374.6 mm (19.09 x 1.72 x 14.75 in)
• Weight: 6.1 kg (13.5 lb)
• ESD/EMP Protection: Air ±24 kV, Contact ±24 kV
• Shock and Vibration: ETSI300-019-1.4 Standard
• Operating Temperature: -5 to 40°C (23 to 104°F)
• Operating Humidity: 5% to 95% noncondensing
• Certifications: CE, FCC, IC

𝐈𝐍𝐓𝐄𝐍𝐃𝐄𝐃 𝐔𝐒𝐄 / 𝐀𝐏𝐏𝐋𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒

• Managed switching for growing UniFi network deployments
• PoE connectivity for compatible network devices
• Fiber network expansion using SFP and SFP+ uplinks
• 10 Gbps SFP+ uplinks for high-capacity network connections
• Centralized configuration and monitoring through UniFi Controller
• Compatible with supported UniFi Access Points and UniFi G3 video cameras as specified by the manufacturer
