Ubiquiti US-8-60W UniFi Switch 8 PoE, 8x GbE with 4x 802.3af PoE, 48 W

Ubiquiti · Routers and Switches

Ubiquiti US-8-60W-5 UniFi Switch 8 PoE, 8x GbE with 4x 802.3af PoE, 48 W, 5-Pack

Part number / SKU
US-8-60W-5
  • 8x GbE RJ45, 4 with PoE
  • External AC/DC adapter
  • Compact desktop, wall
$617.99

Special order· Lead time confirmed by our team after you order.

Warranty
Manufacturer warranty
Request a quote

Need project or contract pricing?

Request project pricing

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

This 5-pack (US-8-60W-5) contains five Ubiquiti UniFi Switch 8 60W units (US-8-60W). Each is a compact managed Layer 2 Gigabit switch for UniFi networks, listed by Ubiquiti as UniFi 8 PoE (Gen1). It has eight GbE RJ45 ports, four of which supply 802.3af PoE at up to 15.4 W each, and it is managed through the UniFi Network application.

Ubiquiti rates it at 16 Gbps switching capacity, 8 Gbps non-blocking throughput and a 12 Mpps forwarding rate, with 256 VLANs and a 16,000 entry MAC table. Total PoE availability is 48 W, and the switch draws up to 12 W excluding PoE output. An external AC/DC adapter powers it, and the fanless steel body sits on a desk or mounts on a wall.

  • Best for: installers deploying several small PoE switches for access points or cameras across a site.
  • System fit: UniFi Network application, version 6.3.51 or later; managed in-band over Ethernet.
  • Important to know: this listing is a 5-pack; on each switch only four of the eight ports supply PoE (802.3af, 48 W total).

Why teams choose it

Built for reliable networks

  • PoE for small sites

    four 802.3af ports at up to 15.4 W each, 48 W total.

  • Silent operation

    fanless SGCC steel enclosure for desk or wall placement.

  • Full Layer 2 control

    VLANs, LACP, 802.1X, IGMP snooping and port mirroring from UniFi Network.

  • Wire-speed switching

    16 Gbps switching capacity and 8 Gbps non-blocking throughput.

Specifications

Technical specifications

General
Brand Ubiquiti
Model US-8-60W
Pack Quantity 5 switches
Device Type Managed Layer 2 PoE switch
Form Factor Compact desktop, wall
Layer L2
Interfaces
Ethernet Ports 8x GbE RJ45, 4 with PoE
Management Interface Ethernet
Performance
Switching Capacity 16 Gbps
Non-blocking Throughput 8 Gbps
Forwarding Rate 12 Mpps
Supported VLANs 256
MAC Address Table 16,000
Packet Buffer 1.5 MB
Access Lists 128 IPv4, 128 MAC
Power
Power Method External AC/DC adapter
Supported Voltage Range 44 to 57 V DC
Max Power Consumption 12 W, excluding PoE output
PoE Standard 802.3af
PoE Budget 48 W
Max PoE per Port 15.4 W
Physical
Dimensions 148 x 100 x 31 mm (5.8 x 3.9 x 1.2 in)
Weight 432 g (15.2 oz)
Enclosure Material SGCC steel
Cooling Fanless
Environmental
Operating Temperature -5 to 45 °C (23 to 113 °F)
Operating Humidity 5 to 95% noncondensing
Software and Management
Management UniFi Network 6.3.51 and later
Layer 2 Features LACP, STP/RSTP, IGMP snooping, 802.1X, DHCP snooping, storm control, port mirroring, jumbo frames, LLDP-MED, voice VLAN, loop protection
Listings and Approvals
Certifications CE, FCC, IC, Anatel
NDAA Compliant
