Ubiquiti UX7-US WiFi 7 10GbE Cloud Gateway Router 2.5GbE
- EhubAmerica SKU
- UX7-US
- Compact desktop
$219.99
In stock
- Warranty
- Manufacturer warranty
Need project or contract pricing?
Request project pricing- Help in English, Spanish and Portuguese
- 30-day returns
Not sure it fits your system? Check compatibility
Overview
What it is and who it is for
PRODUCT OVERVIEW
Mesh-scalable, super-compact 10G Cloud Gateway with integrated WiFi 7.
PRODUCT TYPE
Routers and Switches
KEY FEATURES
- WiFi all-in-one router with 6 GHz support
- 300+ client capacity
- 0.96' information display
- Reset button
- 2.5 GbE RJ45 LAN port
- 1.750 ft coverage (for single unit)
- USB-C power input (adapter included)
- Technical Description
- Overview: Dimensions: 117 x 117 x 42.5 mm (4.61 x 4.61 x 1.67'')
- UniFi Application Suite: Network: ✓
- Managed UniFi Devices: 30
- Simultaneous Users Connected: 300
- Max. WAN Port Count: 1
- Default WAN Ports: (1) 10 GbE RJ45
- IDS/IPS Throughput: 2.3 Gbps
- Form Factor: Compact desktop
- Coverage Area: 160 m² (1,750 ft²)
- Security: Stateful Firewall: ✓
TECHNICAL SPECIFICATIONS
- Brand: Ubiquiti
- Model: UX7-US
- Product Type: Routers/Switches
- WiFi all-in-one router with 6 GHz support
- 300+ client capacity
- 0.96' information display
- Reset button
- 2.5 GbE RJ45 LAN port
- 1.750 ft coverage (for single unit)
- USB-C power input (adapter included)
- Overview: Dimensions: 117 x 117 x 42.5 mm (4.61 x 4.61 x 1.67'')
- UniFi Application Suite: Network: ✓
- Managed UniFi Devices: 30
- Simultaneous Users Connected: 300
- Max. WAN Port Count: 1
- Default WAN Ports: (1) 10 GbE RJ45
- IDS/IPS Throughput: 2.3 Gbps
- Form Factor: Compact desktop
- Coverage Area: 160 m² (1,750 ft²)
- Security: Stateful Firewall: ✓
- Application-Aware Layer 7 Firewall: ✓
- DPI & Traffic Identification: ✓
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps): ✓
- Content Filtering: ✓
- Intrusion Prevention (IPS/IDS): ✓
- Ad Blocking: ✓
- IDS/IPS Signatures: 20,000+ with CyberSecure
- VLAN/Subnet-based Traffic Segmentation: ✓
- VPN & SD-WAN: License-Free SD-WAN: ✓
- Site-to-Site VPN: Site Magic: ✓
- IPsec: ✓
- OpenVPN: ✓
INTENDED USE / APPLICATIONS
- Professional networking and communications deployments
- Commercial, institutional, or industrial installations
- Use with compatible equipment according to manufacturer specifications
Specifications
Technical specifications
| TECHNICAL SPECIFICATIONS: Ubiquiti UX7-US WiFi 7 10GbE Cloud Gateway Router | |
|---|---|
| General | |
| Model | UX7-US |
| Product Name | UniFi Express 7 |
| Form Factor | Compact desktop |
| Managed UniFi Devices | 30 |
| Simultaneous Users Connected | 300 |
| Coverage Area | 160 m² (1,750 ft²) |
| Physical | |
| Dimensions | 117 x 117 x 42.5 mm (4.61 x 4.61 x 1.67") |
| Display | 0.96" information display |
| Power & Electrical | |
| Power Input | USB-C (adapter included) |
| Wireless / RF | |
| WiFi Standard | 802.11a/b/g/n/ac/ax/be (WiFi 6/6E, WiFi 7) |
| 6 GHz Throughput | 5.7 Gbps |
| 6 GHz MIMO | 2 x 2 (DL/UL MU-MIMO) |
| 6 GHz Antenna Gain | 6 dBi |
| 6 GHz Max. TX Power | 24 dBm |
| 5 GHz Throughput | 4.3 Gbps |
| 5 GHz MIMO | 2 x 2 (DL/UL MU-MIMO) |
| 5 GHz Antenna Gain | 7 dBi |
| 5 GHz Max. TX Power | 26 dBm |
| 2.4 GHz Throughput | 688 Mbps |
| 2.4 GHz MIMO | 2 x 2 (DL/UL MU-MIMO) |
| 2.4 GHz Antenna Gain | 4 dBi |
| 2.4 GHz Max. TX Power | 23 dBm |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) |
| Max. BSSIDs | 4 per Radio (Gateway Mode), 4 per Radio (AP Mode) |
| 802.11a Data Rates | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| 802.11b Data Rates | 1, 2, 5.5, 11 Mbps |
| Networking & Connectivity | |
| WAN Ports | 1 x 10 GbE RJ45 |
| LAN Ports | 1 x 2.5 GbE RJ45 |
| Max. WAN Port Count | 1 |
| IDS/IPS Throughput | 2.3 Gbps |
| Stateful Firewall | Yes |
