Ubiquiti · Routers and Switches
Ubiquiti UXG-MAX 2.5G Multi-WAN Gateway 2.3 Gbps IDS/IPS
- EhubAmerica SKU
- UXG-MAX
- USB Type-C (5V DC/3A)
- Compact desktop
$230.99
Special order· Lead time confirmed by our team after you order.
- Warranty
- Manufacturer warranty
Need project or contract pricing?
Request project pricing- Help in English, Spanish and Portuguese
- 30-day returns
Not sure it fits your system? Check compatibility
Overview
What it is and who it is for
PRODUCT OVERVIEW
Compact, multi-WAN independent gateway with full 2.5G support for high-performance networking at small-to-medium sites.
PRODUCT TYPE
Routers and Switches
KEY FEATURES
- Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
- Up to 2.3 Gbps routing with IDS/IPS when using UniFi OS 4.1 or later
- (1) 2.5 GbE WAN port
- (4) 2.5 GbE LAN ports, including (1) remappable to WAN
- USB-C powered (adapter included)
- Managed with UniFi Network 8.1.113 and later
- Compact plug-and-play design
- Status LED
- Reset button
- USB-C power input* *5V DC, 3A USB-C adapter included
- Note: EU Store version includes EU power plug only.
- Technical Specification:
- Overview:
- Dimensions: 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2')
- Default WAN Ports: (1) 2.5 GbE RJ45
- LAN Ports: (4) 2.5 GbE RJ45
- IDS/IPS Throughput: 2.3 Gbps
- Form Factor: Compact desktop
TECHNICAL SPECIFICATIONS
- Brand: Ubiquiti
- Model: UXG-MAX
- Product Type: Networking Accessories
- Managed with a CloudKey, Official UniFi Hosting, or UniFi Network Server
- Up to 2.3 Gbps routing with IDS/IPS when using UniFi OS 4.1 or later
- (1) 2.5 GbE WAN port
- (4) 2.5 GbE LAN ports, including (1) remappable to WAN
- USB-C powered (adapter included)
- Managed with UniFi Network 8.1.113 and later
- Compact plug-and-play design
- Status LED
- Reset button
- USB-C power input* *5V DC, 3A USB-C adapter included
- Note: EU Store version includes EU power plug only.
- Overview: Dimensions: 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2')
- Default WAN Ports: (1) 2.5 GbE RJ45
- LAN Ports: (4) 2.5 GbE RJ45
- IDS/IPS Throughput: 2.3 Gbps
- Form Factor: Compact desktop
- Security: Stateful Firewall
- Application-Aware Layer 7 Firewall
- DPI & Traffic Identification
- Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps)
- Content Filtering
- Intrusion Prevention (IPS/IDS)
- Ad Blocking
- IDS/IPS Signatures 55,000+ With CyberSecure
- VPN & SD-WAN: License-Free SD-WAN
- Site-to-Site VPN: Site Magic
- IPsec
- OpenVPN
- VPN Server: Teleport Zero-Configuration VPN
INTENDED USE / APPLICATIONS
- Professional networking and communications deployments
- Commercial, institutional, or industrial installations
- Use with compatible equipment according to manufacturer specifications
Specifications
Technical specifications
| General | |
|---|---|
| Model | UXG-MAX |
| Brand | Ubiquiti |
| Form Factor | Compact desktop |
| Dimensions | 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2 in) |
| Weight | 520 g (1.1 lb) |
| Enclosure Material | Polycarbonate |
| Power & Electrical | |
| Max. Power Consumption | 9.6 W |
| Power Method | USB Type-C (5V DC/3A) |
| Power Supply | USB Type-C (5V DC/3A) adapter included |
| Supported Voltage Range | 100–240V AC |
| Networking & Connectivity | |
| WAN Ports | (1) 2.5 GbE RJ45 |
| LAN Ports | (4) 2.5 GbE RJ45 (including 1 remappable to WAN) |
| IDS/IPS Throughput | 2.3 Gbps |
| MAC Address Table Size | 2,000 |
| Processor | Quad-core ARM Cortex-A53 at 1.5 GHz |
| System Memory | 2 GB |
| Management | Ethernet, Bluetooth |
| Multi-WAN Load Balancing | Supported |
| Dynamic Routing | OSPF supported |
| VPN Protocols | Site Magic, IPsec, OpenVPN, WireGuard, L2TP |
| SD-WAN | License-Free |
| Security Features | Stateful Firewall, Application-Aware Layer 7 Firewall, DPI & Traffic Identification, Zone-Based Firewall Advanced Filtering, Content Filtering, Intrusion Prevention (IPS/IDS), Ad Blocking |
| IDS/IPS Signatures | 55,000+ with CyberSecure |
| Advanced QoS | Supported |
| Advanced NAT | SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT |
| Integrated RADIUS Server | Supported |
| RADIUS over TLS (RadSec) | Supported |
| Multicast DNS (mDNS) | Supported |
| Environmental | |
| Ambient Operating Temperature | -10 to 40°C (14 to 104°F) |
| Ambient Operating Humidity | 5 to 95% noncondensing |
| ESD/EMP Protection (Air) | ±8 kV |
| ESD/EMP Protection (Contact) | ±4 kV |
| Compatibility | |
| Managed with | CloudKey, Official UniFi Hosting, or UniFi Network Server |
| UniFi Network Version | 8.1.113 and later |
