Yeastar NeoGate TA410 4-Port FXO VoIP Gateway, SIP and IAX2, T.38 Fax

Manufacturer part number
TA410
EhubAmerica SKU
YST-TA410
  • 1x 10/100BASE-T
  • 4x FXO RJ11, 1x 10/100 LAN

Works with: 3CX (interoperable), Asterisk (interoperable), Lync Server (interoperable), FreePBX (interoperable), Yeastar MyPBX (auto-provisioning) Confirmed by the manufacturer


$351.10

Special order· Lead time confirmed by our team after you order.

Warranty
Manufacturer warranty
Request a quote

Need project or contract pricing?

Request project pricing

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The Yeastar NeoGate TA410 is an analog VoIP gateway with 4 FXO ports that connects analog telephone lines (PSTN) or PBX extension interfaces to a VoIP network. It supports SIP (RFC 3261) and IAX2 over UDP, TCP, TLS and SRTP, with one 10/100BASE-T Ethernet port and RJ11 line connectors.

Voice codecs include G.711 A-law and µ-law, G.722, G.723, G.726, G.729A, GSM and ADPCM, with ITU-T G.168 line echo cancellation at 8 to 128 ms, a dynamic jitter buffer, VAD, CNG and PLC. Fax runs over T.38 or T.30 pass-through. The gateway detects caller ID (Bell 202, ETSI V23, NTT, DTMF) and disconnect by busy tone or polarity reversal.

Network features include DHCP, DDNS, OpenVPN, static routes, VLAN, static NAT and STUN, plus a built-in firewall, IP blacklist and attack alert. It is managed through a web GUI, with auto-provisioning through Yeastar MyPBX, HTTP/TFTP firmware upgrades, remote management, packet capture, logs and an API. Yeastar lists interoperability with 3CX, Asterisk, Lync Server and FreePBX.

  • Best for: offices that need to bring 4 analog phone lines or PBX trunks into an IP PBX or VoIP service.
  • System fit: SIP or IAX2 gateway for IP PBXs; Yeastar lists 3CX, Asterisk, Lync Server and FreePBX interoperability and MyPBX auto-provisioning.
  • Important to know: FXO ports connect to telephone lines, not to analog phones; for analog phones an FXS gateway is needed.

Why teams choose it

Built for reliable networks

  • 4 analog lines on IP

    FXO ports connect PSTN lines or PBX extensions to VoIP.

  • Two protocols

    SIP (RFC 3261) and IAX2 with TLS and SRTP transport.

  • Fax support

    T.38 and T.30 pass-through.

  • Line echo cancellation

    ITU-T G.168 with 8 to 128 ms settings.

Specifications

Technical specifications

General
Brand Yeastar
Model NeoGate TA410
Device Type Analog FXO VoIP gateway
Interfaces
Ports 4x FXO RJ11, 1x 10/100 LAN
FXO Ports 4x RJ11
Ethernet Ports 1x 10/100BASE-T
Signaling FXO Loop Start, Kewl Start
Performance
Protocols SIP (RFC 3261), IAX2
Transport UDP, TCP, TLS, SRTP
Voice Codecs G.711 A/µ-law, G.722, G.723, G.726, G.729A, GSM, ADPCM
Fax T.38, T.30 pass-through
Echo Cancellation ITU-T G.168 LEC, 8/16/32/64/128 ms
DTMF RFC 2833, SIP INFO, in-band
Caller ID Bell 202, ETSI V23, NTT V23, DTMF-based
Disconnect Detection Busy tone, polarity reversal
Voice Quality Dynamic jitter buffer, VAD, CNG, PLC
Environmental
Operating Temperature 0 to 40 °C (32 to 104 °F)
Storage Temperature -20 to 65 °C (-4 to 149 °F)
Operating Humidity 10 to 90%, non-condensing
Software and Management
Management Web GUI, auto-provisioning with MyPBX, API
Maintenance Backup/restore, HTTP/TFTP firmware upgrade, remote management, packet capture, logs
Network Features DHCP, DDNS, OpenVPN, static route, VLAN
NAT Traversal Static NAT, STUN
QoS DiffServ, ToS, 802.1p/Q
Security Firewall, IP blacklist, attack alert
Interoperability 3CX, Asterisk, Lync Server, FreePBX
