Dks Doorking 9000-385 Slide Gate Operator 1500lb 35ft 1HP
Product identifier
SKU
9000-385
$3,470.00
Available to order
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
Main features:
- Steel frame provides strength and quiet operation
- “T-Handle” release is easily accessible from front of operator
- Operator re-connects automatically when handle is released
- Direct driven limit nuts for precise gate control
- Auto-close timer 1-30 seconds
- Ports for plug-in open and reverse loop detectors – DKS detectors only
- Selectable loop/reverse input function; stop or reverse
- Anti-tailgating feature helps to control un-authorized traffic
- Standard normally closed stop circuit
- Gate Tracker reporting output provides operator data to DKS access control system
- Convenience outlets for accessory transformers
- Built-in power switch and alarm reset switch
- Simple bi-parting gate interface
Physical and Electrical Characteristics:
- Maximum supported weight 1500 lb (680 Kg)
- Maximum gate length 35 ft (10.7 m)
- Continuous equipment use
- Operator supply 115 Vac
- Current consumption 9.7 Amp
- 1 HP continuous-duty motor
Highlights:
- Operation class I, II, III, and IV.
- Two voltage outlets for accessories.
- It has two ports for Doorking mass sensors.
Slide Gate Operator, continuous use for sliding doors of 1500 pounds and 35ft
Features:
- Powerful and quiet operation.
- Limit adjusters for precise control of door movement.
- Automatic closing timer from 1 to 30 seconds.
- Voltage outputs for connection of accessories.
- Starter switch is incorporated into the equipment.
- Activation of the equipment using dry contact.
Additional notes:
- Includes 6 meters of chain; for longer door applications, it is necessary to purchase additional chain sections.
- The compatible chain is of the model 2600-442, sold in lengths of 6 meters. 2600-442
- For 2-blade applications, add a secondary motor (purchased separately)
Key Features
- 1 HP Motor for Powerful and Quiet Operation
- Continuous 24/7 Duty Cycle for Commercial Applications
- Adjustable Limit Switches for Precise Gate Movement Control
- Automatic Close Timer From 1 to 30 Seconds
- Dual Voltage Outputs for Accessory Connections
- Dual Ports for Compatible DoorKing Mass Sensors
