Motorola APX 900 UHF 450-520 MHz P25 Portable Radio 512 Channels H92SDH9PW7AN

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐈𝐓𝐋𝐄
Motorola APX 900 UHF 450–520 MHz P25 Portable Radio 512 Channels H92SDH9PW7AN

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐎𝐕𝐄𝐑𝐕𝐈𝐄𝐖
Motorola APX 900 UHF single-band P25 portable radio supporting 450–520 MHz operation with 512 channel capacity. Designed for secure voice and data communications with P25 interoperability, Bluetooth 4.0 LE, integrated GPS/GLONASS, and IP68-rated durability.

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐘𝐏𝐄 / 𝐂𝐀𝐓𝐄𝐆𝐎𝐑𝐘
Two-Way Radios
UHF Portable Radios

𝐊𝐄𝐘 𝐅𝐄𝐀𝐓𝐔𝐑𝐄𝐒
• Frequency band: UHF 450–520 MHz
• 512 channel capacity
• Project 25 (P25) compliant
• Clear or digital-encrypted ASTRO® 25 trunked operation
• Analog MDC-1200 and P25 conventional system configurations
• Embedded digital signaling (ASTRO and ASTRO 25)
• Bluetooth 4.0 (LE)
• Integrated GPS/GLONASS for outdoor location tracking
• Intelligent Priority Scan
• Text messaging
• Audio profiles
• User-programmable voice announcement
• Instant recall
• Single-Key Advanced Digital Privacy (ADP) encryption
• AES-256 encryption (optional)
• Dual-knob design (volume and channel/talkgroup)
• IP68 water and dust protection (2 meters, 2 hours)
• Meets MIL-STD-810 C, D, E, F and G
• IMPRES battery compatible

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐓𝐄𝐂𝐇𝐍𝐈𝐂𝐀𝐋 𝐒𝐏𝐄𝐂𝐈𝐅𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒
GENERAL
• Model: H92SDH9PW7AN
• Frequency Range: 450–520 MHz
• Channel Spacing: 12.5 / 20 / 25 kHz
• Channel Capacity: 512
• Flash Memory: 2 GB
• Rated RF Output Power: 1–5W
• Frequency Stability: ±1.0 ppm
• Maximum Frequency Separation: Full Bandsplit

RECEIVER (TYPICAL)
• Analog Sensitivity (12 dB SINAD): 0.234 µV
• Digital Sensitivity (5% BER): 0.207 µV
• Intermodulation: 77.0 dB
• Spurious Rejection: -80.3 dB
• Selectivity (12.5/25 kHz): -67/-76 dB

TRANSMITTER (TYPICAL)
• FM Hum and Noise (12.5/25 kHz): -45/-47 dB
• Audio Distortion: 1.0%
• Emissions (conducted and radiated): -75 dBc

BLUETOOTH
• Version: Bluetooth 4.0 (LE)
• Secure Simple Pairing
• Connections: Up to 6 data + 1 audio

GPS/GNSS
• Constellations: GPS and GLONASS
• Tracking Sensitivity: -154 dBm
• Accuracy: <10 m (95%)
• Cold/Hot Start: <60 s (95%)
• Mode of Operation: Autonomous (non-assisted)

PHYSICAL (WITH STANDARD BATTERY PMNN4491B)
• Length: 5.1 in (130 mm)
• Width: 2.2 in (55 mm)
• Thickness: 1.4 in (36 mm)
• Weight: 11 oz (315 g)

ENVIRONMENTAL
• Operating Temperature: -30°C to +60°C
• Storage Temperature: -40°C to +85°C
• Water and Dust Intrusion: IP68 (2 meters, 2 hours)
• ESD: IEC 61000-4-2
• Housing Color: Black

ENCRYPTION
• Supported Algorithms: ADP, AES-256 (AES-256 optional)
• Encryption Keys per Radio: 48
• Encryption Type: Digital
• Standards: FIPS 140-2 Level 1; FIPS 197

POWER SUPPLY
• Compatible Battery: IMPRES Li-Ion 2100 mAh (PMNN4491B)
• Alternate battery options available

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐒𝐇𝐈𝐏𝐏𝐈𝐍𝐆
• Handling time: up to 2 business days
• Orders often ship the same business day
• Orders are not shipped on weekends or holidays
• Carrier is seller-selected (UPS, USPS, FedEx, or equivalent)
• Shipping delays may occur during high-volume periods or carrier-related issues

Shipping Restrictions:
• Shipments to Alaska, Hawaii, Puerto Rico, or Guam may be cancelled due to cost
• Orders over $100 require a valid postal address
• Orders over $250 require insurance and signature confirmation
• International buyers are responsible for customs duties and import taxes
• Restricted destinations: Cuba, Iran, North Korea, Sudan, Syria, Russia

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐑𝐄𝐓𝐔𝐑𝐍𝐒
• Returns accepted within 30 days
• Item must be returned in the same condition as received
• Seller pays return shipping

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐃𝐀𝐓𝐀 𝐀𝐂𝐂𝐔𝐑𝐀𝐂𝐘 𝐃𝐈𝐒𝐂𝐋𝐀𝐈𝐌𝐄𝐑
Product details are based on available manufacturer information and may be subject to change without notice.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐁𝐔𝐋𝐊 / 𝐕𝐎𝐋𝐔𝐌𝐄 𝐁𝐔𝐘𝐄𝐑𝐒
For bulk orders or volume inquiries, please contact us to confirm availability and pricing.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
