Cambium Networks C000000L033B Gigabit Surge Suppressor (56V)

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐈𝐓𝐋𝐄
Cambium Networks C000000L033B Gigabit Ethernet Surge Suppressor 56V

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐎𝐕𝐄𝐑𝐕𝐈𝐄𝐖
Gigabit Ethernet surge suppressor designed for lightning protection of compatible Cambium Networks equipment. Supports 1000 Base T, 56 V nominal voltage, and pole or wall mounting.

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐘𝐏𝐄 / 𝐂𝐀𝐓𝐄𝐆𝐎𝐑𝐘
Networking
Networking Accessories

𝐊𝐄𝐘 𝐅𝐄𝐀𝐓𝐔𝐑𝐄𝐒
• Gigabit Ethernet surge suppression
• Line-to-line and line-to-ground protection
• TVS diode surge arrestor technology
• 5 nanoseconds typical response time
• Compatible with PMP 450i Access Point and Subscriber Module, PTP 450i, and PTP 820S
• Suitable for pole or wall mounting
• IP54 environmental protection
• 200 mph wind survival rating

𝐓𝐄𝐂𝐇𝐍𝐈𝐂𝐀𝐋 𝐒𝐏𝐄𝐂𝐈𝐅𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒
• Brand: Cambium Networks
• Part Number: C000000L033B
• Product Type: Gigabit Ethernet Surge Suppressor
• Transfer Rate: 1000 Base T
• Connectors: Two RJ-45 cables
• Nominal Voltage: 56 V
• Protection Mode: Line-to-line and line-to-ground
• Surge Arrestor: TVS Diodes
• Surge Current Rating, L-G, Total: 172 A, 10/1000 µs
• Response Time: 5 nanoseconds typical
• Mounting: Pole mount or wall mount
• Dimensions: 118 x 87.5 x 46.5 mm (4.6 x 3.4 x 1.8 in)
• Weight: 156 g (0.34 lbs)
• Wind Survival: 321 kph (200 mph)
• Operating Temperature: -40°C to 60°C (-40°F to 140°F)
• Humidity: 100% condensing
• Environmental Protection: IP54
• Compliance: UL/cUL 62368 / IEC 62368 Edition 2

𝐈𝐍𝐓𝐄𝐍𝐃𝐄𝐃 𝐔𝐒𝐄 / 𝐀𝐏𝐏𝐋𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒
• Designed for lightning protection to minimize potential damage to outdoor wireless broadband equipment
• Compatible with PMP 450i Access Point and Subscriber Module, PTP 450i, and PTP 820S
• Suitable for wall-mounted or pole-mounted installations
• Network operators should follow applicable grounding and lightning protection best practices
