D-Link DGS-1008MP 8-Port Gigabit PoE+ Unmanaged Switch, 125 W PoE Budget

Part number / SKU
DGS-1008MP
  • 8x 1 GbE RJ45 PoE+
  • AC, 100 to 240 V
  • Desktop or 1U rackmount

$98.81

In stock

Warranty
Manufacturer warranty

Free Economy shipping available at checkout

Need project or contract pricing?

Request project pricing
  • Help in English, Spanish and Portuguese

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The D-Link DGS-1008MP is an unmanaged 8-port Gigabit switch with IEEE 802.3at PoE+ on all eight ports, made for small offices and businesses that power wireless access points, IP cameras and VoIP phones over Ethernet. It is plug and play with no configuration needed.

Each port delivers up to 30 W, with a total PoE budget of 125 W. D-Link rates the 16 Gbps switching fabric at 1,488,000 pps per Gigabit port, with store and forward switching and a 192 KB packet buffer. The fanless metal housing is 280 x 180 x 44 mm (1U) for desktop or rack use, runs on 100 to 240 V AC and operates from 0 to 40 °C.

  • Best for: small office and business networks that power PoE access points, IP cameras and VoIP phones.
  • System fit: unmanaged plug and play Gigabit switch; works with standard IEEE 802.3at and 802.3af PoE devices.
  • Important to know: the 125 W budget is shared across all eight ports, so eight devices at a full 30 W each exceed it.

Why teams choose it

Built for reliable networks

  • PoE+ on every port

    eight Gigabit ports with up to 30 W each under IEEE 802.3at.

  • Shared 125 W budget

    one PoE pool across the eight ports, up to 30 W on any single port.

  • Quiet operation

    fanless design for offices and other occupied spaces.

  • Desktop or rack

    1U metal housing at 280 mm wide for desk or rack installation.

Specifications

Technical specifications

Product identifiers
SKUDGS-1008MP
General
Brand D-Link
Model DGS-1008MP
Device Type Unmanaged PoE+ switch
Form Factor Desktop or 1U rackmount
Management Unmanaged, plug and play
Interfaces
Ethernet Ports 8x 1 GbE RJ45 PoE+
Standards IEEE 802.3i, 802.3u, 802.3ab, 802.3at
Auto MDI/MDI-X Supported
Cabling Cat 5/5e UTP or STP up to 100 m
Performance
Switching Capacity 16 Gbps
Forwarding Rate 1,488,000 pps per Gigabit port
Transmission Method Store and forward
Packet Buffer 192 KB
Power
PoE Standard IEEE 802.3at PoE+
PoE Per Port Up to 30 W
PoE Budget 125 W
Power Method AC, 100 to 240 V
AC Input 100 to 240 V AC, 50/60 Hz
Physical
Dimensions 280 x 180 x 44 mm (11.02 x 7.08 x 1.73 in)
Cooling Fanless
Housing Metal
LEDs Per port link/activity/speed and PoE status, PoE Max
Environmental
Operating Temperature 0 to 40 °C
Storage Temperature -10 to 70 °C
Operating Humidity 0 to 95% RH, non-condensing
