CommScope DB404-B 450-470MHz 5.9dBi Omnidirectional Radio Antenna
Product identifier
SKU
DB404-B
$1,200.50
Available to order
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
Frequency Band, MHz 450–470
Gain, dBi 5.9
Beamwidth, Horizontal, degrees 360
Beamwidth, Vertical, degrees 27.0
Beam Tilt, degrees 0
VSWR | Return Loss, dB 1.5 | 14.0
Input Power per Port, maximum, watts 250
Polarization Vertical
Impedance 50 ohm
Key Features
- Omnidirectional Coverage With 360-Degree Horizontal Beam
- 27-Degree Vertical Beamwidth for Precise Signal Control
- Low 1.5:1 VSWR for Maximum Power Transfer Efficiency
- Continuous Grounding for Lightning Protection and Safety
- Aluminum Radiator Construction for Durability and Performance
- Includes Pipe Mount Kit for 1.25-3.5 inch Diameter Tubes
