Fanvil A320i 10.1 Touch Screen Android IP Phone 20 SIP Lines PoE WiFi Dual-Band

PRODUCT OVERVIEW

Fanvil A320i Android console IP phone with 20 SIP lines, 10.1-inch touch screen, 112 DSS softkeys, adjustable 8 MP camera, HD audio, dual Gigabit Ethernet, PoE, Bluetooth 5.0, and dual-band Wi-Fi.

PRODUCT TYPE

IP Phones

KEY FEATURES

• 20 SIP lines
• Android 9.0 operating system
• 10.1-inch 1280 x 800 color touch screen
• 112 DSS softkeys
• Adjustable 8-megapixel camera with mechanical privacy shutter
• HD audio through speaker and handset
• Gooseneck directional microphone
• 10-party audio conferencing
• 3-party video conferencing
• H.264 video codec support
• Built-in Bluetooth 5.0
• Built-in dual-band Wi-Fi
• 2.4 GHz Wi-Fi: 802.11 b/g/n
• 5 GHz Wi-Fi: 802.11 a/n/ac
• Dual Gigabit Ethernet ports
• Integrated PoE
• Local phonebook with up to 2,000 entries
• Remote XML/LDAP phonebook with up to 2,000 entries
• SIP Hotspot and group broadcasting
• Supports third-party application installation

TECHNICAL SPECIFICATIONS

• Brand: Fanvil
• Model: A320i
• Operating System: Android 9.0
• SIP Lines: 20
• Display: 10.1-inch color touch screen
• Display Resolution: 1280 x 800
• DSS Softkeys: 112
• Camera: 8 MP, adjustable angle
• Camera Privacy: Mechanical shutter
• Video Call Resolution: CIF / VGA / 4CIF / 720P / 1080P
• Video Decoding: H.264; H.265 optional
• Video Bandwidth: 64 kbps to 4 Mbps
• Video Frame Rate: 5 to 30 fps
• Image Formats: JPEG / PNG / BMP
• Video Format: MP4
• Narrowband Audio Codecs: G.711a/u, G.729AB, iLBC
• Wideband Audio Codecs: G.722, Opus
• Audio Features: AEC, NR, PLC, adaptive jitter buffer
• DTMF: In-band, RFC2833 / SIP INFO
• Bluetooth: 5.0
• Wi-Fi 2.4 GHz: 802.11 b/g/n
• Wi-Fi 5 GHz: 802.11 a/n/ac
• Ethernet: 10/100/1000 Mbps
• Ethernet Ports: 2 x RJ45, Network and PC
• Network Mode: IPv4
• IP Configuration: Static / DHCP
• Network Access Control: 802.1x
• SIP Protocol: SIP 2.0 over UDP/TCP/TLS
• Additional Protocols: RTP/RTCP/SRTP, STUN, DHCP, CDP, LLDP, SNTP, FTP/TFTP, HTTP/HTTPS, TR-069
• VPN: OpenVPN with third-party application support
• USB: 1 x USB 2.0 Type-A
• Handset Ports: 2 x RJ9
• Power: DC 5V/2A or PoE
• PoE Power Consumption: 2W to 9.77W
• Adapter Power Consumption: 1.2W to 7.75W
• Operating Temperature: 0°C to 45°C
• Operating Humidity: 10% to 95%
• Installation: Desktop
• Device Dimensions, Stand Angle 1: 309 x 214 x 187 mm
• Device Dimensions, Stand Angle 2: 309 x 226 x 167 mm
• Gooseneck Microphone Frequency Response: 20 Hz to 20 kHz
• Gooseneck Microphone SNR: ≥60 dB at 1 kHz / 1 Pa
• Manufacturer-documented components: PTM handset, standard RJ9 handset wire, 1.5 m CAT5 Ethernet cable, gooseneck microphone, and back rack
• Standard handset and PTT handset: Optional

INTENDED USE / APPLICATIONS

Designed as a visualization paging console phone for industry customers. Manufacturer-stated applications include management centers and command centers for video calling, two-way intercom, monitoring, and broadcasting.
