FANVIL
Fanvil i61 2MP 1080p IP66 Video Door Phone 2 SIP Lines
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
PRODUCT OVERVIEW
Based on SIP and ONVIF protocols , i61 is a video door phone that integrates powerful functionalities of access control, intercom, and security protection . Featuring an aluminum alloy design and single speed dial touch button , i61 delivers a high-quality robust appearance . With high protection level IP66 and IK07 , it is waterproof, dustproof and anti-collision in most outdoor environments . i61 allows users to make audio/video calls via a speed-dial button and a 2 Mega-pixel camera and achieve access control by different modes. With rich input and output interfaces , i61 is easy to link with other security devices and customize into various solutions in apartments, commercial buildings, communities and industrial parks.
PRODUCT TYPE
VoIP
KEY FEATURES
• With high protection level of IP66 and IK07, wide temperature range from -40℃ to 70℃, it can work perfectly in most outdoor environments
• Support to open the door with RFID/IC cards, NFC, indoor switch, remote DTMF, Timed open door
• Aluminum alloy design and single speed-dial touch button
• Built in 2M pixels wide-angle camera: 120º(H), 60º(V) with infrared night-vision feature
• Fitted with a tamper switch that detects unauthorized opening of the device itself
• Compatible with SIP and ONVIF protocols
• Built-in 3 short-in detect ports and 2 short-out control ports, can be integrated with induction loop antenna
• Built-in maximum 128GB capacity TF card slot for image storage
• HD voice speech quality with built-in 2.5W speaker and Acoustic Echo Canceller.
• 159.7x88x36.15 mm
• Generic 2 SIP lines
• Video intercom
• IP address announcement in English
• Programmable DSS key
• RS485 port: Support
• Wiegand port: Support
• Switch signal input and output
• Door control in and out
TECHNICAL SPECIFICATIONS
• Brand: Fanvil
• Model: i61
• Product Type: IP Phones
• With high protection level of IP66 and IK07, wide temperature range from -40℃ to 70℃, it can work perfectly in most outdoor environments
• Support to open the door with RFID/IC cards, NFC, indoor switch, remote DTMF, Timed open door
• Aluminum alloy design and single speed-dial touch button
• Built in 2M pixels wide-angle camera: 120º(H), 60º(V) with infrared night-vision feature
• Fitted with a tamper switch that detects unauthorized opening of the device itself
• Compatible with SIP and ONVIF protocols
• Built-in 3 short-in detect ports and 2 short-out control ports, can be integrated with induction loop antenna
• Built-in maximum 128GB capacity TF card slot for image storage
• HD voice speech quality with built-in 2.5W speaker and Acoustic Echo Canceller.
• 159.7x88x36.15 mm
• Generic 2 SIP lines
• Video intercom
• IP address announcement in English
• Programmable DSS key
• RS485 port: Support
• Wiegand port: Support
• Switch signal input and output
• Door control in and out
• Line-out for induction loop antenna: Support
• Support TF card
• PoE enabled
• Open the door operation: DTMF, RFID card, NFC, indoor switch, Time open door
• RFID cards (support 10,000)
• Door open records (support 200,000)
• Device Functions Auto-answering
• Programmable DSS keys
• Through button or web page volume adjustment
• Network time synchronization
• Time Plan (task management)
INTENDED USE / APPLICATIONS
• Business voice communications
• Office, reception, and institutional environments
• Integration with compatible SIP/VoIP systems
