Epcom GABVID1R3 DVR/NVR Security Cabinet Steel 20G Rack Mount

Functional Characteristics:

• Fully removable front cover.
• Double plastic window on the front.
• Belt with clasp to hold the recorder.
• Side vents.
• Features perforations to be fixed to a table or desk.
• Compatible with 19" rack installation adding the accessory

Application and Operation:

The team's goal is to safely safeguard your DVR / NVR to prevent:

• Access to buttons to turn off or modify established settings.
• Disconnection of network or power cabling (in equipment).
• Direct physical damage to the casing due to blows from other elements.

Physical Characteristics:

• Application: indoor.
• Material: Steel Gauge 20.
• Weight: 2.91 Kg.
• Outdoor cabinet dimensions:
  • Width: 364 mm
  • Height: 73 mm
  • Depth: 457 mm
• Fan compatibility: 60 x 60 mm (2 Pcs).
• Passthrough: 100 x 41 mm.

Physical Characteristics: Maximum Dimension of VCR to Protect:

• Width: 315 mm
• Height: 62 mm
• Depth: 288 mm

Paint:

• Black color semi-matte note.
• Applied by electrostatic 5-step baking process: degreasing, rinsing, iron phosphate, rinsing, and sealing.
• Paint: base polyester.

Key Features

• Fully Removable Front Panel for Quick Equipment Access
• Dual Mica Windows for Clear Visual Status Monitoring
• 19" Rack Mount Compatible With Optional Accessory
• Security Strap With Buckle for Secure DVR Retention
• 20 Gauge Steel Construction With Baked Electrostatic Paint
• Side Ventilation and Mounting Holes for Secure Installation
