Linkedpro LP-60100-24U-R2 24U Floor Standing Network Cabinet Glass Door

Product identifier
SKU LP-60100-24U-R2
$1,450.50
Available to order

Lead time confirmed after order.

Request a quote Need help confirming fit? Talk to a specialist →
  • Product availability confirmed before fulfillment.
  • Support in English, Spanish and Portuguese.
  • 30-day returns and RMA support.

Product details

Highlighted Features:
  • Installation Type: Floor-standing.
  • Front Door: Security 3-point lock with tempered glass window.
  • Removable Side Panels: With lock.
  • Adjustable Rack Posts: The 4 rack posts can be moved forward or backward for better equipment installation.
  • Security Locks: Unique key for each lock.
  • Removable Doors: With the option to change door swing direction.
  • Fan Support: Ready for 1 LP-VENT-03 or LP-VENT-02V2 fan set (not included).
  • Levelers Included.
  • Wheels Sold Separately: Model LP-CAST-72-SET.
  • Ships Assembled.
Application:
  • Video surveillance systems
  • Backup power units
  • Internet service distribution
  • Two-way radio communication
  • General radio communication
  • Copper and fiber cabling management

Included Components:

  • Metal body (side covers, rack posts, front and rear doors)
  • Black assembly screws
  • Hardware for mounting up to 3 devices on rack posts (32 cage nuts, 32 screws, 32 washers)
  • Levelers
  • 1 basic cable organizer: LP-ORG-45S
  • Packaging
Physical Specifications:
  • Application: Indoor use
  • Material: Premium-grade steel
  • Compliance: Manufactured according to ANSI/TIA RS-310-D standard
  • Weight: 67.69 kg / 149.26 lbs (without packaging)
  • Load Capacity: 567 kg / 1,249.17 lbs total
  • Max Load per Unit: 23 kg / 50.71 lbs
  • Dimensions: 600 x 1170 x 1058 mm / 23.62 x 46.06 x 41.65 in (Width x Height x Depth)
  • Rack Units: 24U
  • Max Working Depth: 920 mm / 36.22 in
  • Color: Semi-matte black
  • Finish: Polyester baked paint process




Key Features

  • Three-Point Security Locking System on Front Glass Door
  • Removable Side Panels With Individual Security Locks
  • Adjustable Rack Posts for Custom Equipment Installation
  • Fan Mounting Preparation for Optional Cooling Systems
  • Includes Leveling Feet, Optional Casters Sold Separately
  • Pre-Assembled Cabinet for Immediate Installation and Use
