Linkedpro LP-60100-42U-R2 42U Floor Cabinet Glass Door Security Lock

Product identifier
SKU LP-60100-42U-R2
$1,700.50
Available to order

Lead time confirmed after order.

Request a quote Need help confirming fit? Talk to a specialist →
  • Product availability confirmed before fulfillment.
  • Support in English, Spanish and Portuguese.
  • 30-day returns and RMA support.

Product details

Highlighted Features:
  • Installation Type: Floor.
  • Front door with 3-point security lock and tempered glass window.
  • Removable side panels with locks.
  • Adjustable rack posts for better equipment installation.
  • Security locks with a unique key for each lock.
  • Removable doors with an option to change the opening direction.
  • Fan preparation for one LP-VENT-03 set or one LP-VENT-02V2 (not included).
  • Leveling feet included.
  • Wheels sold separately, model LP-CAST-72-SET.
  • Pre-assembled shipping.
Applications:
  • Video surveillance systems.
  • Backup power units.
  • Internet service distribution.
  • Two-way radio communication.
  • Cable management for copper and fiber cabling.

Included Equipment:

  • Metal body (side panels, rack posts, front and rear doors).
  • Black screws for assembly.
  • Hardware for installing three devices on rack posts (56 cage nuts, 56 screws, and 56 washers).
  • Leveling feet.
  • One simple cable organizer (LP-ORG-45S).
  • Packaging.
Physical Characteristics:
  • Application: Indoor.
  • Material: Premium-grade steel.
  • Manufactured according to ANSI/TIA RS-310-D standards.
  • Weight: 224.12 lbs (without packaging).
  • Load capacity: 2795 lbs / 1268 Kg.
  • Maximum load per unit: 50.71 lbs / 23 Kg.
  • Dimensions: 23.62 x 77.56 x 41.65 inches (Width x Height x Depth).
  • Dimensions (mm): 600 x 1970 x 1058 mm
  • Rack Units: 42.
  • Maximum working depth: 36.22 inches / 920 mm.
  • Color: Semi-matte black.
  • Finish: Polyester-based baked enamel paint.

Key Features

  • Front Door With 3-Point Security Lock and Tempered Glass Window
  • Removable Side Panels With Locking Mechanism for Secure Access
  • Adjustable Rack Posts for Flexible Equipment Installation Options
  • Pre-Wired for LP-VENT-03 or LP-VENT-02V2 Cooling Fan Systems
  • Reversible Door Opening Direction for Custom Installation Layouts
  • Includes Cable Management Organizer and Leveling Feet
