MikroTik CRS418-8P-8G-2S+5axQ2axQ-RM-US 16-Port PoE Switch 10G SFP+ WiFi 6

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐈𝐓𝐋𝐄

MikroTik CRS418-8P-8G-2S+5axQ2axQ-RM-US 16-Port PoE Switch 10G SFP+ WiFi 6

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐎𝐕𝐄𝐑𝐕𝐈𝐄𝐖

The MikroTik CRS418-8P-8G-2S+5axQ2axQ-RM-US is a powerful all-in-one Layer 3 managed switch, router, and Wi-Fi 6 access point , designed to simplify modern network deployments. Combining 16 Gigabit Ethernet ports , PoE-out support , dual 10G SFP+ uplinks , and integrated 4x4 MIMO dual-band Wi-Fi 6 , this device replaces multiple network components in a single compact 1U rackmount solution.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐘𝐏𝐄 / 𝐂𝐀𝐓𝐄𝐆𝐎𝐑𝐘

Networking
Routers and Switches

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

𝐊𝐄𝐘 𝐅𝐄𝐀𝐓𝐔𝐑𝐄𝐒

• 16 x Gigabit Ethernet ports (8 with PoE-out)
• 2 x 10G SFP+ ports for high-speed uplinks
• Integrated dual-band Wi-Fi 6 (802.11ax) with 4x4 MIMO
• Quad-core 2.2 GHz ARM CPU for routing and processing
• L3 hardware offloading for high-performance switching
• RouterOS v7 with advanced networking features
• USB 3.0 port for storage and configuration tools
• Dedicated Gigabit management port with direct CPU access
• Dual redundant power supplies (100-240V AC)
• Up to 150W total PoE output power
• High-density wired connectivity
• Integrated wireless coverage
• Centralized routing and traffic control
• Clean and efficient rack deployments
• Small and medium business networks
• ISP and WISP deployments
• Office network consolidation (switch + router + AP)
• Surveillance systems with PoE cameras

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

𝐓𝐄𝐂𝐇𝐍𝐈𝐂𝐀𝐋 𝐒𝐏𝐄𝐂𝐈𝐅𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒

• Brand: MikroTik
• Model: CRS418-8P-8G-2S+5axQ2axQ-RM-US
• Product Type: Routers and Switches
• 16 x Gigabit Ethernet ports (8 with PoE-out)
• 2 x 10G SFP+ ports for high-speed uplinks
• Integrated dual-band Wi-Fi 6 (802.11ax) with 4x4 MIMO
• Quad-core 2.2 GHz ARM CPU for routing and processing
• L3 hardware offloading for high-performance switching
• RouterOS v7 with advanced networking features
• USB 3.0 port for storage and configuration tools
• Dedicated Gigabit management port with direct CPU access
• Dual redundant power supplies (100-240V AC)
• Up to 150W total PoE output power
• High-density wired connectivity
• Integrated wireless coverage
• Centralized routing and traffic control
• Clean and efficient rack deployments
• Small and medium business networks
• ISP and WISP deployments
• Office network consolidation (switch + router + AP)
• Surveillance systems with PoE cameras
• High-speed fiber uplink environments
• Advanced RouterOS labs and enterprise setups
• Specifications Product code: CRS418-8P-8G-2S+5axQ2axQ-RM
• Architecture: ARM 64bit
• CPU: IPQ-8072A
• CPU core count: 4
• CPU nominal frequency: 2208 MHz
• CPU Threads count: 4
• Switch chip model: 98DX226S
• RouterOS license: 5
• Operating System: RouterOS v7
• Size of RAM: 1 GB
• Storage size: 128 MB
• Storage type: NAND
• MTBF: Approximately 200'000 hours at 25C
• Tested ambient temperature: -20°C to 70°C
• Powering Number of AC inputs: 2
• AC input range: 100-240
• Number of PSU slots: 2
• Frequency (Hz): 50-60
• Max power consumption: 227 W
• Max power consumption without attachments: 43 W
• Cooling type: 4 fans
• PoE-out PoE-out ports: Ether9-Ether16
• PoE out: 802.3af/at
• Low voltage PoE-Out current limit: 1.1 A
• High voltage PoE-Out current limit: 0.56 A
• Total output power: 150
• Wireless specifications Wireless 2.4 GHz Max data rate: 1148 Mbit/s
• Wireless 2.4 GHz Number of chains: 4
• Wireless 2.4 GHz standards: 802.11b/g/n/ax
• Antenna gain dBi for 2.4 GHz: 5
• Wireless 2.4 GHz chip model: QCN-5024
• Wireless 2.4 GHz generation: Wi-Fi 6
• Wireless 5 GHz Max data rate: 2400 Mbit/s
• Wireless 5 GHz Number of chains: 4
• Wireless 5 GHz standards: 802.11a/n/ac/ax
• Antenna gain dBi for 5 GHz: 6
• Wireless 5 GHz chip model: QCN-5054
• Wireless 5 GHz generation: Wi-Fi 6
• Ethernet 10/100/1000 Ethernet ports: 17
• Number of 1G Ethernet ports with PoE-out: 8
• Fiber SFP+ ports: 2
• Peripherals Serial console port: RJ45
• Number of USB ports: 1
• USB Power Reset: Yes
• USB slot type: USB 3.0 type A
• Max USB current (A): 1
• Other CPU temperature monitor: Yes
• Current Monitor: Yes
• PCB temperature monitor: Yes
• Voltage Monitor: Yes
• Mode button: Yes
• Package Contents CRS418-8P-8G-2S+5axQ2axQ-RM-US
• 2 x AC power cables (IEC)
• Rackmount fastening kit (K-100)
• Preinstalled RouterOS v7 license

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━

𝐈𝐍𝐓𝐄𝐍𝐃𝐄𝐃 𝐔𝐒𝐄 / 𝐀𝐏𝐏𝐋𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒

Designed for professional network switching, routing, uplink, aggregation, and infrastructure deployments.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
