𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐈𝐓𝐋𝐄
Mimosa N5-X12 4.9-6.4GHz Horn Antenna for C5x 12 dBi
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐎𝐕𝐄𝐑𝐕𝐈𝐄𝐖
The Mimosa N5-X12 is a compact 12 dBi horn antenna designed for the Mimosa C5x platform, supporting 4.9-6.4 GHz operation with high noise immunity and flexible deployment for point-to-point and point-to-multipoint wireless networks.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐘𝐏𝐄 / 𝐂𝐀𝐓𝐄𝐆𝐎𝐑𝐘
Networking – Antennas (Networking)
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐊𝐄𝐘 𝐅𝐄𝐀𝐓𝐔𝐑𝐄𝐒
• Designed for Mimosa C5x wireless platforms
• 12 dBi antenna gain
• Supports 4.9-6.4 GHz frequency range
• Twist-on antenna mounting design
• Suitable for PtP and PtMP deployments
• Best-in-class noise immunity
• Ultra-rugged construction
• Low-power deployment support
• Compact horn antenna form factor
• High front-to-back and front-to-side isolation performance
• FCC and CE regulatory compliance
• RoHS and WEEE compliant
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐓𝐄𝐂𝐇𝐍𝐈𝐂𝐀𝐋 𝐒𝐏𝐄𝐂𝐈𝐅𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒
• Brand: Mimosa
• Model: N5-X12
• Product Type: Horn Antenna
• Compatible Platform: Mimosa C5x
• Frequency Range: 4.9-6.4 GHz
• Gain: 12 dBi
• Front-to-Back Ratio: 29 dB
• Front-to-Side Ratio: 27 dB
• Diameter: 76 mm (2.99 in)
• Depth: 67 mm (2.64 in)
• Weight: 0.16 kg (0.35 lb)
• Deployment Modes: PtP / PtMP
• Regulatory Approvals: FCC Part 15.405, FCC Part 90Y, CE/ETSI
• EMI/Safety Compliance: FCC Part 15 Class B, EN 55022 Class B, IEC61000, UL/IEC 60950-2, IEC/EN 60905-1
• WEEE/RoHS Compliant: Yes
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐈𝐍𝐄𝐍𝐃𝐄𝐃 𝐔𝐒𝐄 / 𝐀𝐏𝐏𝐋𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒
• Point-to-point wireless backhaul
• Point-to-multipoint wireless deployments
• Outdoor broadband infrastructure
• High-noise RF environments
• Enterprise and WISP wireless networks
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐒𝐇𝐈𝐏𝐏𝐈𝐍𝐆
• Handling time: up to 2 business days
• Orders often ship the same business day
• Orders are not shipped on weekends or holidays
• Carrier is seller-selected (UPS, USPS,FedEx, or equivalent)
• Shipping delays may occur during high-volume periods or carrier-related issues
• Shipments to Alaska, Hawaii, Puerto Rico, or Guam may be cancelled due to cost
• Orders over $100 require a valid postal address
• Orders over $250 require insurance and signature confirmation
• International buyers are responsible for customs duties and import taxes
• Restricted destinations: Cuba, Iran, North Korea, Sudan, Syria, Russia
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐑𝐄𝐓𝐔𝐑𝐍𝐒
• Returns accepted within 30 days
• Item must be returned in the same condition as received
• Seller pays return shipping
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐃𝐀𝐓𝐀 𝐀𝐂𝐂𝐔𝐑𝐀𝐂𝐘 𝐃𝐈𝐒𝐂𝐋𝐀𝐈𝐌𝐄𝐑
Product details are based on available manufacturer information and may be subject to change without notice.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐁𝐔𝐋𝐊 / 𝐕𝐎𝐋𝐔𝐌𝐄 𝐁𝐔𝐘𝐄𝐑𝐒
For bulk orders or volume inquiries, please contact us to confirm availability and pricing.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐀𝐁𝐎𝐔𝐓 𝐄𝐇𝐔𝐁 𝐀𝐌𝐄𝐑𝐈𝐂𝐀
eHub America is a U.S.-based technology distributor specializing in two-way communications, networking, and security solutions. We operate with strict catalog standards, manufacturer-verified product data, and dependable order fulfillment. Our focus is serving professional, commercial, and institutional customers with consistency, accuracy, and operational reliability.
