NetPoint NPTR-1 Parabolic Antenna 30 dBi 4.9-6.4 GHz Dual Polarization N-Female

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐈𝐓𝐋𝐄
NetPoint NPTR-1 Parabolic Antenna 30 dBi 4.9-6.4 GHz Dual Polarization N-Female

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐎𝐕𝐄𝐑𝐕𝐈𝐄𝐖
NetPoint's NPTR5-DP high-performance parabolic antenna is designed to work with very high performance in both licensed and unlicensed bands with excellent gai n. The NPTR5-SDP model has dual polarization and an N-female connector, as well as exceptional VSRW performance in the 4.9 to 6.4 GHz operating band . The antenna comes with galvanized materials and alloys, has an integrated radome for high wind protection , and reliable operation in the most demanding conditions . This parabolic antenna has a size of 2ft and can be used for PTP backhaul or in maritime environments.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐏𝐑𝐎𝐃𝐔𝐂𝐓 𝐓𝐘𝐏𝐄 / 𝐂𝐀𝐓𝐄𝐆𝐎𝐑𝐘
Networking
Antennas (Networking)

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐊𝐄𝐘 𝐅𝐄𝐀𝐓𝐔𝐑𝐄𝐒
• Gain of up to 30 dBi with low VSWR and high port isolation across the entire 4.9-6.4 GHz band
• One antenna that covers 5 and 6 Ghz
• Reduced interference with 38 dB minimum front to back
• Simplifies installation on site and guarantees “factory-tested” quality
• Connector type N Female
• 28.34 x 28.34 x 11.41in (72cm X 72cm X 29cm)
• 14.3lb (6.5kg)
• Eletric Specifications Antenna type: Directional parabolic reflector
• Frequency: 4.9 - 6.4 Ghz
• Connector type: Female N
• Gain (dBi): 28, 30, 29 - 4.9GHz, 5.4GHz and 5.7GHz
• VSWR HPOL: <1.5
• Beamwidth VPOL: 6.0°
• Beamwidth HPOL: 6.2°
• Return loss: 11
• ISO (dB): 30
• Radius F/B (dB): 38
• Polarization: Dual slant 45° or 90°

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐓𝐄𝐂𝐇𝐍𝐈𝐂𝐀𝐋 𝐒𝐏𝐄𝐂𝐈𝐅𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒
• Brand: NetPoint
• Model: NPTR-1
• Product Type: Antennas (Networking)
• Gain of up to 30 dBi with low VSWR and high port isolation across the entire 4.9-6.4 GHz band
• One antenna that covers 5 and 6 Ghz
• Reduced interference with 38 dB minimum front to back
• Simplifies installation on site and guarantees “factory-tested” quality
• Connector type N Female
• 28.34 x 28.34 x 11.41in (72cm X 72cm X 29cm)
• 14.3lb (6.5kg)
• Eletric Specifications Antenna type: Directional parabolic reflector
• Frequency: 4.9 - 6.4 Ghz
• Connector type: Female N
• Gain (dBi): 28, 30, 29 - 4.9GHz, 5.4GHz and 5.7GHz
• VSWR HPOL: <1.5
• Beamwidth VPOL: 6.0°
• Beamwidth HPOL: 6.2°
• Return loss: 11
• ISO (dB): 30
• Radius F/B (dB): 38
• Polarization: Dual slant 45° or 90°
• Mechanical Specifications Wind max survival speed (MPH): 124.2 miles with Radome
• Azimuth adjustment: +/- 60 degrees
• Elevation adjustment (°): +/- 15 degrees
• Mounting Pipe Diameter, Min: 1 inch - 25.4mm
• Mounting Pipe Diameter, Max: 2.750 inch 69.86mm
• Operating temperature (C°): -49 to +140 F° | -45 to +60 C°
• Connector type: Dual N-Female with pigtails for RP-SMA
• Lenght of Pig tail: 2ft - 600 mm

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐈𝐍𝐓𝐄𝐍𝐃𝐄𝐃 𝐔𝐒𝐄 / 𝐀𝐏𝐏𝐋𝐈𝐂𝐀𝐓𝐈𝐎𝐍𝐒
• Outdoor wireless networking links
• Point-to-point or point-to-multipoint deployments
• Pole, mast, or tower installations where compatible

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐒𝐇𝐈𝐏𝐏𝐈𝐍𝐆
• Handling time: up to 2 business days
• Orders often ship the same business day
• Orders are not shipped on weekends or holidays
• Carrier is seller-selected (UPS, USPS, FedEx, or equivalent)
• Shipping delays may occur during high-volume periods or carrier-related issues
• Shipments to Alaska, Hawaii, Puerto Rico, or Guam may be cancelled due to cost
• Orders over $100 require a valid postal address
• Orders over $250 require insurance and signature confirmation
• International buyers are responsible for customs duties and import taxes
• Restricted destinations: Cuba, Iran, North Korea, Sudan, Syria, Russia

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐑𝐄𝐓𝐔𝐑𝐍𝐒
• Returns accepted within 30 days
• Item must be returned in the same condition as received
• Seller pays return shipping

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐃𝐀𝐓𝐀 𝐀𝐂𝐂𝐔𝐑𝐀𝐂𝐘 𝐃𝐈𝐒𝐂𝐋𝐀𝐈𝐌𝐄𝐑
Product details are based on available manufacturer information and may be subject to change without notice.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
𝐁𝐔𝐋𝐊 / 𝐕𝐎𝐋𝐔𝐌𝐄 𝐁𝐔𝐘𝐄𝐑𝐒
For bulk orders or volume inquiries, please contact us to confirm availability and pricing.

━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
