Notifier FCM-1 Addressable Control Module for NAC and Speaker Circuits

Part number / SKU
FCM-1
  • Addressable control module
  • Addressable
  • 4 in square x 2.125 in deep box
  • 15 to 32 VDC
  • UL, ULC, FM, CSFM, MEA, FDNY

Works with: SMB500 surface-mount backbox, CB500 control module barrier, A2143-20 capacitor (Class A speaker), Notifier intelligent fire alarm control panels Confirmed by the manufacturer


$96.17

Special order· Lead time confirmed by our team after you order.

Warranty
Manufacturer warranty

Free Economy shipping available at checkout

Need project or contract pricing?

Request project pricing
  • Help in English, Spanish and Portuguese

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The Notifier FCM-1 is an addressable control module that gives a Notifier intelligent fire alarm control panel a supervised circuit for notification appliances such as horns, strobes and speakers. It is powered by the two-wire SLC loop and switches on command from the panel.

The module switches 24 VDC NAC power or audio up to 70.7 Vrms from an external supply that is relay isolated from the SLC, with up to 3 A on Class B wiring or 2 A on Class A wiring. It draws 350 µA average on direct poll, uses one of 159 addresses on FlashScan loops (99 on CLIP), and mounts in a 4 in square, 2.125 in deep box.

The SMB500 surface box and CB500 barrier are available for mounting, and the A2143-20 capacitor is required for Class A (Style Z) speaker operation. For new FlashScan releasing applications Notifier refers to the FCM-1-REL.

  • Best for: switching horn, strobe and speaker circuits on Notifier intelligent fire alarm systems.
  • System fit: Notifier intelligent fire alarm control panels on FlashScan or CLIP SLC loops.
  • Important to know: it needs a separate regulated 24 VDC or 70.7 Vrms supply for the load circuit; installation and programming must be done by a qualified fire alarm technician in line with local code and the panel manufacturer's instructions.

Why teams choose it

Built for fire alarm systems

  • NAC or audio switching

    controls 24 VDC notification power or speaker audio up to 70.7 Vrms.

  • Class A or B

    supports Class B (Style Y) or Class A (Style Z) NAC and speaker wiring.

  • Flexible addressing

    uses one of 159 addresses on FlashScan loops or 99 on CLIP loops.

  • Wiring separation

    the CB500 barrier separates power-limited and non-power-limited wiring in the box, as UL requires.

Specifications

Technical specifications

Ask about a spec
Product identifiers
SKUFCM-1
General
Brand Notifier
Model FCM-1
Device Type Addressable control module
Addressing Addressable
Addressing Detail 01 to 159 on FlashScan, 01 to 99 on CLIP; rotary switches
Protocol FlashScan and CLIP
Output One supervised NAC or speaker circuit, Class B (Style Y) or Class A (Style Z)
Indicators LED blinks green on each poll
Wiring Terminals SEMS screws with clamping plates
Electrical
Operating Voltage 15 to 32 VDC
Maximum Current 6.5 mA (LED on)
Average Operating Current 350 µA direct poll; 375 µA group poll; 485 µA max (LED flashing, NAC shorted)
External Supply Regulated 24 VDC (NAC) or 70.7 Vrms, 50 W (speakers)
External Supply Drain 1.7 mA max at 24 VDC; 2.2 mA max at 80 Vrms
Maximum NAC Current 3 A Class B wiring; 2 A Class A wiring
Maximum NAC Line Loss 4 VDC
Physical
Dimensions 4.5 in H x 4 in W x 1.25 in D (114.3 x 101.6 x 31.75 mm)
Mount Type 4 in square x 2.125 in deep box
Mount Type Detail SMB500 surface box
Face Plate Off-white, heat-resistant plastic
Environmental
Operating Temperature 32°F to 120°F (0°C to 49°C)
Relative Humidity 10% to 93% non-condensing
Listings and Approvals
Agency Approvals UL, ULC, FM, CSFM, MEA, FDNY
Approval Details UL Listed S635; ULC S3705 (A version); FM Approved; CSFM 7300-0028:0219; MEA 14-00-E; FDNY COA #6067 and #6065
