Planet GSD-603F 5-Port Gigabit Ethernet Switch with 1 SFP Slot

Part number / SKU
GSD-603F
  • 5x 1 GbE RJ45
  • External 5 V DC adapter
  • Desktop

Works with: PLANET MGB-SX SFP (multimode), PLANET MGB-LX SFP (single-mode), PLANET MFB-FX SFP (multimode), PLANET MFB-F20 SFP (single-mode) Confirmed by the manufacturer


$70.99

In stock

Warranty
Manufacturer warranty

Free Economy shipping available at checkout

Need project or contract pricing?

Request project pricing
  • Help in English, Spanish and Portuguese

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The Planet GSD-603F is a compact unmanaged desktop switch with five 10/100/1000BASE-T RJ45 ports and one 1000BASE-X SFP slot. Planet positions it for homes, small offices and workgroups, and for fiber access designs such as FTTH, FTTC and FTTB, where the SFP slot brings a fiber link straight into the switch.

The SFP slot reaches 550 m on multimode fiber or 10 to 120 km on single-mode fiber, depending on the module. Switching is store and forward with a 12 Gbps fabric, 8.9 Mpps throughput, 2K MAC entries, a 1.5 Mbit shared buffer and 9K jumbo frames. The 162 x 102 x 28 mm metal case runs from an external 5 V DC, 1 A supply, draws up to 0.6 W with the system on and up to 4.1 W at full Ethernet load, supports IEEE 802.3az Energy Efficient Ethernet and is rated for 0 to 50 °C.

  • Best for: homes, small offices and workgroups, and FTTH, FTTC or FTTB fiber access points that need a fiber uplink.
  • System fit: unmanaged Layer 2 plug-and-play switch; the SFP slot takes standard 1000BASE-X modules for multimode or single-mode fiber.
  • Important to know: SFP modules are sold separately, and fiber distance depends on the module chosen.

Why teams choose it

Built for reliable networks

  • Fiber uplink

    one 1000BASE-X SFP slot, up to 550 m multimode or 10 to 120 km single-mode depending on the module.

  • Low power draw

    about 4.1 W at full load with IEEE 802.3az Energy Efficient Ethernet.

  • Plug and play

    auto-negotiation and auto MDI/MDI-X, so no crossover cables are needed.

  • Compact metal case

    162 x 102 x 28 mm and 398 g for desktop installs where space is limited.

Specifications

Technical specifications

Ask about a spec
Product identifiers
SKUGSD-603F
General
Brand Planet
Model GSD-603F
Device Type Unmanaged Gigabit switch with SFP
Form Factor Desktop
Layer L2
Enclosure Metal
Interfaces
Ethernet Ports 5x 1 GbE RJ45
SFP Ports 1x 1000BASE-X SFP
Auto MDI/MDI-X RJ45 ports
Fiber Reach 550 m multimode; 10 to 120 km single-mode, depending on SFP module
Performance
Switch Architecture Store and forward
Switching Capacity 12 Gbps
Forwarding Rate 8.9 Mpps
MAC Address Table 2K entries
Packet Buffer 1.5 Mbit shared
Jumbo Frames 9K
Flow Control Back pressure for half duplex; IEEE 802.3x pause frame for full duplex
Power
Power Method External 5 V DC adapter
DC Input 5 V DC, 1 A
Power Consumption 0.6 W max system on; 4.1 W max at full Ethernet load
Energy Efficiency IEEE 802.3az
Physical
Dimensions 162 x 102 x 28 mm
Weight 398 g
Environmental
Operating Temperature 0 to 50 °C
Operating Humidity 10 to 90% RH, non-condensing
Storage Temperature -40 to 70 °C
Storage Humidity 5 to 90% RH, non-condensing
Software and Management
Management Unmanaged, plug and play
Listings and Approvals
Standards IEEE 802.3, 802.3u, 802.3ab, 802.3z, 802.3x, 802.3az
