Fiberhome PLC-104-S PLC 1:4 Micro Splitter without Connectors

FIBERHOME

Fiberhome PLC-104-S PLC 1:4 Micro Splitter without Connectors

Product identifier
SKU PLC-104-S
$26.65
Available to order

Lead time confirmed after order.

Request a quote Need help confirming fit? Talk to a specialist →
  • Product availability confirmed before fulfillment.
  • Support in English, Spanish and Portuguese.
  • 30-day returns and RMA support.

Product details

1x4 PLC Optical Splitter

High-Precision Micro Encapsulation Technology

Network Efficiency Reimagined

The FiberHome **PLC (Planar Lightwave Circuit)** Splitter is a high-performance component engineered for FTTx networks. Using patented low-loss technology, it provides an even 1x4 optical split across wavelengths ranging from **1260 to 1650nm**. Its micro-encapsulation design allows it to be seamlessly integrated into underground, aerial, pole, and rack-mount systems where space is at a premium.

Industry Compliance

  • ✓ Standards: Fully Telcordia GR-1209 & GR-1221 compliant.
  • ✓ Fiber Type: Premium G.657A Low Bend Sensitivity.
  • ✓ Eco-Friendly: RoHS directive compliant materials.
  • ✓ Loss Tech: Ultra-low insertion and polarization loss.
  • ✓ Durability: Rugged micro-steel tube encapsulation.

Optical Properties

Split Ratio: 1 x 4
Wavelength Range: 1260 ~ 1650 nm
Pigtail Diameter: 0.035" (0.9 mm)
PDL / WDL: <0.3dB / <0.5dB
Directivity: >55 dB

Versatile Deployment Applications

FTTx / FTTH
LAN / WAN
CATV Networks
Test & Measurement
Installation Note: This micro-encapsulation splitter features 0.035" (0.9mm) loose tube pigtails without connectors, allowing for custom field termination or fusion splicing inside splice trays, distribution boxes, or OSP pedestals.

Key Features

  • Planar Lightwave Circuit Technology for Efficient Network Performance
  • Low Insertion Loss of 7.2 dB With High Port Uniformity
  • Operates in Extreme Temperatures From -40°F to 185°F
  • Compliant With Telcordia GR-1209 and GR-1221 Standards
  • Compact Design for Underground, Aerial, and Rack Mount Applications
  • ROHS Compliant Materials for Environmental Safety
