Epcom PLI-48-DC-8A 48V 8A DIN Rail Isolated Power Supply
Product identifier
SKU
PLI-48-DC-8A
$71.99
Out of stock
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
Product Introduction:
- Isolated type of Din Rail power supply
- The conversion efficiency of this model is higher than 88%
- It has output over-current protection, short circuit protection, over-voltage protection, constant output voltage and so on.
Technical Parameters:
- Input voltage: 100-240Vac 50/60 Hz
- Range of adjustable voltage: 48Vdc +/- 1.5V
- Storage humidity: 10~95%RH
- Working humidity: 20~90%RH, No condensation
- Input current: 6.0 A MAX
- Output current: 8A
- Operating temperature: -20~60℃
- Storage temperature: -25~85℃
- Load loss: 1W
Structure Size:
- Dimensions: L212mm * W115mm * H30mm
- Being available for DIN Rail: TS35/7.5 or 35/15
Key Features
- 48V DC Output With ±1.5V Regulation for Stable Power Delivery
- Standard TS35/7.5 DIN Rail Mounting for Easy Industrial Installation
- 88% Minimum Conversion Efficiency for Energy Savings
- Comprehensive Protection Against Overcurrent and Short Circuits
- Wide 100-240V AC Input Range for Global Voltage Compatibility
- Extended Temperature Range From -4°F to 140°F Operation
