Planet POE-E201 802.3at Gigabit PoE Extender 1640ft Range

Extends the range of transmission/supply PoE 802.3at 328 ft (100 m). Additional. Supports Chain Connection. Reaches up to 656 ft (200 m). Totals with PoE + Extensor.

Protection:
-Auto detects devices PoE 802.3at, protects the equipment of damages for wrong installation.
-Protection against electrostatic discharge ESD and Transitory EFT of 2KV.

Max. Distance:
-Devices PoEat (25W) up to 656 ft (200 m)
-Devices PoEat Class 2 (6.5W) up to1640 ft (500 m)
-Devices PoEat Class 3 (12.9W) up to 1312 ft (400 m)

Ports:
-1 Port of Input 10/100/1000Base-TX with PoE 802.3at
-1 Port of Output 10/100/1000Base-TX with PoE 802.3af/at

Physical and Electric Features:
-Does not require supply
-Metallic, mount in wall
-Dimensions: 3.7 x 2.75 x 1.02" (94 x 70 x 26 mm)
-Weight: 0.43 lb (197 g)
-Operating temperature: 14 to 140°F (-10 to 60°C)

Key Features

• Extends PoE and Gigabit Ethernet up to 1640 ft over CAT5/5e/6 cable
• Supports daisy chain installation of up to 4 units for maximum reach
• Automatic PoE 802.3af detection for plug-and-play operation
• Operating temperature range from 14°F to 140°F for reliable performance
• Compact wall-mount design for space-efficient installation
• Protection against damage from improper installation and power faults
