Linkedpro PRO-CAT-6A Cat6A Ethernet Cable 500MHz 10Gbps Gigabit
Product identifier
SKU
PRO-CAT-6A
$293.54
Available to order
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
The category 6A cable is a high performance LINKEDPRO cable (ANSI / TIA / EIA-568-C.2 Cat 6A) is a cable standard for Gigabit Ethernet and other network protocols. Reaches up to 500 MHz frequencies in each pair and a speed of 1 Gbps. Connecting to the RJ45 connector pin which in principle has better immunity to interference above 100Mbps.
Main Features:
- Video surveillance Megapixel IP / analog video Facilities
- Local high-speed networks
- Wireless Networks
- For high-speed data, Fast Ethernet and Gigabit Ethernet.
- Facilities Gigabit voice/data.
Electrical an Physical Features:
- Conductor: Copper.
- For indoor installations.
- Exterior Color: Blue.
- AWG: 23.
- Insulation: PVC.
- Unshielded.
- Diameter: 0.30" (7.8 mm).
- Frequency: 500 MHz.
Approvals and Certifications:
- UL : E488955
- ANSI / TIA
- ISO / IEC
- CENELEC EN
- ANSI / TIA-568-C.2
- ISO / IEC 11801 2nd Edition Class EA
- CENELEC EN 50173-1
- CENELEC EN 50288-10-1
Type:
ISO / IEC = Information technology: Generic cabling Cabling commercial establishments.
TIA-568-C.2 = Estandart to components and telecommunications cabling compensated twisted pair.
* Price per reel of 100ft.
Key Features
- 10 Gbps Data Transfer Speed for High-Performance Networks
- 500 MHz Frequency Bandwidth for Superior Signal Stability
- 23 AWG Pure Solid Copper Conductors for Maximum Performance
- Meets ANSI/TIA/EIA-568-C.2 Cat6A Standards and Requirements
- 7.8 mm Diameter With PVC Insulation for Easy Installation
- CM Rated for Commercial Building In-Wall Applications
