Linkedpro PRO-CAT5-EXT-LITE Outdoor Gigabit Ethernet Cable UTP PoE CMX UV 1000ft
Product identifier
SKU
PRO-CAT5-EXT-LITE
$239.99
Available to order
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
UL LISTED • CMX • HIGH-SPEED PERFORMANCE
PRO-CAT5-EXT-LITE
OUTDOOR WEATHERPROOF SOLUTION
The perfect solution for cable runs that require being exposed to the weather. Fast and Gigabit Ethernet transfer on extreme conditions, designed by professional security integrators.
Key Characteristics
- Applications: Designed for High-speed, Fast Ethernet, Gigabit Ethernet, and 10BASE-T/100BASE-T data applications.
- Security Ready: Perfect for Megapixel IP video surveillance and Analog video installations.
- Outdoor Rated: Built for outdoor installations (CMX) with superior UV protection.
- Versatile Net: Ideal for Gigabit voice/data installations, wireless networks, and high-speed local networks.
- Long Distance PoE: Reliable power and data transmission over long distances.
High-Durability Outdoor Cable Reel
Physical & Electrical Specs
| Conductor: | Solid 24 AWG Copper |
| Material: | 100% Pure Copper |
| Construction: | UTP (Unshielded Twisted Pair) |
| Outer Diameter: | 0.24" (6.2 mm) |
Standards & Certifications
- UL Listed: Compliant (E488955)
- Environment: CMX Rated (Outdoor)
- Telecommunications: ANSI / TIA
- International Standards: ISO / IEC
- European Standards: CENELEC EN
- Environmental Compliance: RoHS
Product Support & Installation
* Price per reel of 1000 ft (305 m).
Key Features
- 100% Solid Copper Conductors With UV Protection for Outdoor Use
- Supports Gigabit Ethernet for High-Speed Data and Voice
- PoE Compatible for Extended Distance Power Delivery
- Meets ANSI/TIA 568 C.2 and IEC 61156-5 Performance Standards
- 24 AWG Solid Copper With 6.2 mm Overall Diameter
- CMX Rated for Direct Burial and Outdoor Exposed Installations
