Resideo Honeywell 748 Self-Contained Dual Tone Siren, 12 VDC, 119 dB

Part number / SKU
748

$54.98

In stock

Warranty
Manufacturer warranty

Free Economy shipping available at checkout

Need project or contract pricing?

Request project pricing
  • Help in English, Spanish and Portuguese

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The Resideo (Honeywell Home) 748 is a self-contained dual tone siren for wired intrusion and fire alarm panels. It produces a steady or warble tone, selected by which power lead is used, with a rated output of 119 dB at 10 ft.

It is rated 12 VDC and draws 1.2 A maximum. The red lead gives the warble tone, the yellow lead the steady tone and the black lead is the negative return; two white leads connect a built-in SPST tamper switch rated 6 A at 125 VAC or 3 A at 250 VAC. The tamper proof, weather resistant housing mounts directly to a 4 in electrical box or a wall, so no cabinet is needed.

  • Best for: loud audible alarm output from a wired burglary or household fire alarm panel.
  • System fit: alarm control panel bell or siren outputs rated for a 12 VDC, 1.2 A self-contained siren.
  • Important to know: the UL 985 household fire warning listing is for indoor use only; outdoor use applies only to UL 464 and UL 1023 applications.

Why teams choose it

Built for secure sites

  • Loud output

    119 dB at 10 ft.

  • Two tones

    steady or warble selected by wiring.

  • Tamper switch

    built-in SPST tamper on two white leads.

  • No cabinet needed

    mounts on a 4 in electrical box or wall.

Specifications

Technical specifications

Ask about a spec
Product identifiers
SKU748
General
Brand Resideo (Honeywell Home)
Model 748
Device Type Self-contained dual tone siren
Tones Steady and warble
Sound Output 119 dB minimum at 12 VDC, 10 ft on axis, A-weighted
Impedance 8 ohm
Tamper SPST, 6 A at 125 VAC or 3 A at 250 VAC
Wiring Black negative return; red positive warble; yellow positive steady; two white tamper leads
Electrical
Operating Voltage 12 VDC
Current Draw 1.2 A maximum at 12 VDC
Physical
Mount Type 4 in electrical box or wall surface, supplied screws and anchors
Housing Tamper proof, weather resistant, no cabinet required
Environmental
Environment Indoor or outdoor (outdoor per UL 464 and UL 1023 applications)
Listings and Approvals
Agency Approvals UL 985 (indoor use only); UL 464 and UL 1023 (indoor or outdoor)
