Simplex · Fire Alarm

Simplex 2084-9002 Surface Mount Firefighter Telephone Assembly with Handset, Type 4590-B

Part number / SKU
2084-9002
  • Firefighter telephone assembly
  • 4590-B
  • Surface

Works with: 2975-9053 red back box, 4100ES series firefighter telephone controls, 4081-9008 end-of-line resistor harness, 10 kohm Confirmed by the manufacturer


$268.14

Special order· Lead time confirmed by our team after you order.

Warranty
Manufacturer warranty

Need project or contract pricing?

Request project pricing
  • Help in English, Spanish and Portuguese

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The Simplex 2084-9002 is a surface mount firefighter telephone assembly (type 4590-B) for Simplex firefighter telephone systems. The assembly includes the phone, mounting plate and door, with the phone behind a locked door marked LOCAL FIRE EMERGENCY PHONE, and it connects to a dedicated two-wire telephone circuit from the master firefighter telephone control.

The assembly mounts on a 2975-9053 red back box, ordered separately, one per assembly. The two-wire telephone circuits are supervised and power-limited and typically use twisted shielded pair wiring, and each Class B phone circuit uses a 10 kohm, 1/2 W end-of-line resistor harness. Doors and trim are painted red with white silk-screened lettering. Up to six remote phones plus the master can be in use at once, depending on the master control.

  • Best for: surface mounted firefighter telephone stations on Simplex firefighter telephone systems.
  • System fit: 4100ES series firefighter telephone controls on a dedicated two-wire phone circuit; mounts on a 2975-9053 back box.
  • Important to know: the 2975-9053 back box is ordered separately; installation must be done by a qualified fire alarm technician in line with local code.

Why teams choose it

Built for fire alarm systems

  • Supervised circuit

    two-wire telephone circuits are supervised and power-limited.

  • Locked door

    the handset sits behind a locked door marked LOCAL FIRE EMERGENCY PHONE.

  • Shared use

    up to six remote phones plus the master can talk at the same time, depending on the master control.

  • Includes the essentials

    phone, mounting plate and door assembly come together for mounting on the back box.

Specifications

Technical specifications

Ask about a spec
Product identifiers
SKU2084-9002
General
Brand Simplex
Model 2084-9002
Type 4590-B
Device Type Firefighter telephone assembly
Includes Phone, mounting plate and door assembly
Door Locked door, no break-rod
Door Marking LOCAL FIRE EMERGENCY PHONE
Simultaneous Use Up to 6 remote phones plus the master, depending on the master control
Electrical
Circuit Dedicated two-wire telephone circuit, supervised and power-limited
Wiring Twisted shielded pair typical
End-of-Line 10 kohm, 1/2 W resistor harness, one per Class B phone circuit
Physical
Mount Type Surface
Back Box 2975-9053 red back box, ordered separately, one per assembly
Finish Red door and trim with white silk-screened lettering
