Simplex 4606-9202 Color Touchscreen LCD Remote Annunciator for 4007ES, Red Trim

Part number / SKU
4606-9202
  • Remote annunciator
  • 18 to 32 VDC, system supplied

Works with: Simplex 4007ES fire alarm control panel, Red surface mount box (12-1/4 x 4-1/2 x 2-1/2 in), Red semi-flush adapter (12-1/4 x 4-1/2 x 1-3/4 in), RUI overvoltage protectors Confirmed by the manufacturer


$433.99

In stock

Warranty
Manufacturer warranty

Need project or contract pricing?

Request project pricing
  • Help in English, Spanish and Portuguese

Not sure it fits your system? Check compatibility

Overview

What it is and who it is for

The Simplex 4606-9202 is a remote annunciator with a 4.3 in backlit color touchscreen LCD and red trim for 4007ES fire alarm control panels. It connects over RUI, and up to six annunciators can be used per panel.

Panel LEDs show Alarm and Priority 2 (red), Supervisory, Trouble and Alarm Silenced (yellow) and AC power (green), and three programmable control switches have status LEDs and custom labels. A keyswitch, removable only in the disabled position, and passcode-protected user levels control access, and a local tone-alert sounds at the unit. It runs on 18 to 32 VDC from the system and draws 45 mA standby (20% backlight), 70 mA active and 124 mA in alarm.

RUI uses 18 AWG unshielded twisted pair: Class B T-tap wiring up to 10,000 ft total and 2,500 ft to the farthest device, or Class X up to 2,500 ft, with overvoltage protectors at each end. The annunciator measures 13 x 5.21 x 2 in and mounts in a matching red surface box or a semi-flush adapter for existing 2-gang, 4-gang, 6-gang or 4 in square boxes.

  • Best for: remote status display and control of a 4007ES system at a second location.
  • System fit: Simplex 4007ES fire alarm control panels, up to six annunciators per panel over RUI.
  • Important to know: the surface box or semi-flush adapter is sold separately; installation and programming must be done by a qualified fire alarm technician per local code.

Why teams choose it

Built for fire alarm systems

  • Color touchscreen

    4.3 in backlit display for system status and events.

  • Remote control

    three programmable switches with status LEDs and custom labels.

  • Controlled access

    keyswitch plus passcode-protected user levels.

  • Long RUI runs

    up to 10,000 ft total on Class B T-tap wiring.

Specifications

Technical specifications

Ask about a spec
Product identifiers
SKU4606-9202
General
Brand Simplex
Model 4606-9202
Device Type Remote annunciator
Device Type Detail Color touchscreen LCD
Trim Color Red
Display 4.3 in (109 mm) diagonal color touchscreen, backlit
Panel LEDs Alarm, Priority 2 (red); Supervisory, Trouble, Alarm Silenced (yellow); AC power (green)
Control Switches 3 programmable, with status LEDs and custom labels
Access Keyswitch (key removable only when disabled); passcode-protected user levels
Audible Local tone-alert sounder
Communications RUI
Annunciators per Panel Up to 6
Electrical
Operating Voltage 18 to 32 VDC, system supplied
Standby Current 45 mA (backlight at 20%)
Active Current 70 mA
Alarm Current 124 mA (full backlight, tone sounding)
Power Wiring Two 18 to 12 AWG conductors plus dedicated earth ground
RUI Wiring 18 AWG unshielded twisted pair; shielded where it leaves the building, runs 500 ft or more in conduit, or is bundled with IDNet or TrueAlert
RUI Distance, Class B Up to 10,000 ft total T-tap; 2,500 ft to farthest device
RUI Distance, Class X Up to 2,500 ft
RUI Line Limits 0.58 µF maximum capacitance; 35 Ω maximum total line resistance
Physical
Dimensions 13 x 5.21 x 2 in (330 x 132 x 51 mm)
Flush Mounting 5-gang box, 2-1/2 in (64 mm) deep
Surface Box Red, 12-1/4 x 4-1/2 x 2-1/2 in, sold separately
Semi-Flush Adapter Red, 12-1/4 x 4-1/2 x 1-3/4 in, for existing 2-gang, 4-gang, 6-gang or 4 in square boxes
Environmental
Operating Temperature 32 to 120 °F (0 to 49 °C)
Humidity Up to 93% RH, non-condensing at 100 °F (38 °C)
