Zkteco SYSCA-2R-2D 2-Door Access Control Terminal 30000 Cards

Features
- Access control

Capacity
- Cards: 30,000
- Passwords: 30,000
- Events: 100,000
(Up to 32 GB Expandable Events Memory with SD Memory)

Communication
- TCP / IP and RS485
- Input: multi-format Wiegand

Hardware
- Metal cabinet
- Includes 12VDC power / 3A battery charger

Access Control Functions
- Access control by schedules and doors
- Verification Methods:
• Card + Password (with Reader SYSKR602EKB)
- Multi-user verification
- Interlock
- Anti-passback
- Energized relay function

Connections
- 2 relay output NC / NO / COM for board
- 2 Auxiliary relay output NC / NO / COM
- 2 Auxiliary output
- Exit button and magnetic sensor

Power
- 12VDC / 100mA
- Includes 12VDC / 3A power (Battery not included).

Compatible Readers
- Proximity:
• SYSKR600E and SYSKR601E
• Supports 2 readers per door

- Proximity with the keyboard:
• SYSKR602EKB
• Supports 2 readers per door

- Long Range Readers:
• PRO6RF and PRO12RF
• Supports 2 readers per door




Additional Information
- Operating Temperature: 0-55 ° C
- Dimensions: 380 x 290 x 80 mm
- Includes Management Software (in Spanish)

Note:
Support is only provided to the software or equipment supplied by EhubAmerica using the same database included in the package. Any other software, version, or database implementation voids the support, and it becomes the integrator's or developer's responsibility.

Configurations

Key Features

• Supports 30,000 Cards and 30,000 User Passwords Capacity
• Expandable Event Memory up to 32GB via SD Card Slot
• Includes 12V DC 3A Power Supply with Battery Charger
• 2 Relay Outputs NC/NO/COM for Electric Strikes per Door
• Compatible with ZK-Access3.5 and ZKBioCVAccess Software
• Compact Design with Integrated Metal Enclosure Included
