Tycon Power TP-SW5G-VERSA PoE Switch 44-57VIn 5 Port MultiOut GigE PoE

The Tycon Power TP-SW5G-VERSA is a 5-port unmanaged Gigabit Layer 2 PoE switch engineered for demanding industrial and outdoor network deployments where a single power feed must serve mixed PoE device ecosystems. Accepting a wide 46–58 VDC input via wire terminal, the switch eliminates the need for multiple power supplies by delivering three distinct PoE output profiles from one unit: a high-power 60 W 4-pair passive PoE port for bandwidth-hungry endpoints, three IEEE 802.3at 30 W ports for standard powered devices, and a 24 V 12 W passive PoE port for legacy or lower-voltage equipment. The shielded, surge-protected design and included DIN rail mounting kit make it a natural fit for control cabinets, utility enclosures, and industrial automation environments where reliability and installation flexibility are non-negotiable.

Key features & benefits

• Versatile Multi-Output PoE Architecture — A single switch simultaneously provides a 60 W 4-pair passive PoE port, three IEEE 802.3at 30 W PoE ports, and a 24 V 12 W passive PoE port, allowing one device to power a diverse mix of network endpoints without additional injectors or converters.
• Wide 46–58 VDC Input Range — The wire-terminal DC input accepts 46 to 58 VDC, making the switch compatible with standard 48 V telecom and industrial power plants as well as solar or battery-backed DC bus systems that may fluctuate across that range.
• Unmanaged Gigabit Layer 2 Switching — All five ports operate at Gigabit Ethernet speeds on a plug-and-play unmanaged Layer 2 fabric, eliminating configuration overhead while delivering the throughput needed for HD video, VoIP, and data-intensive industrial applications.
• Defined 4-Pair and 2-Pair PoE Pinouts — The 4-pair port uses pins 1,2,4,5 V+ and 3,6,7,8 V−; the 2-pair port uses pins 4,5 V+ and 7,8 V−. Clearly specified pinouts simplify field wiring, troubleshooting, and compatibility planning with passive PoE endpoints.
• Industrial-Grade Shielding and Surge Protection — Integrated shielding and surge protection guard connected equipment and the switch itself against transient voltage events common in outdoor cabinet, rooftop, and industrial control environments.
• DIN Rail Mounting Kit Included — The included DIN rail kit enables fast, secure installation inside standard industrial enclosures and control panels without additional hardware or custom fabrication.
