Txpro TXP-D30-C5X 30dBi Dual Polarization Sector Antenna 4.9-6.5GHz C5x
Product identifier
SKU
TXP-D30-C5X
$193.79
Available to order
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
Electrical Specification
- Frequency Range 4.9 to 6.5 GHz
- 30 dBi gain
- VSWR <2.0
- Double polarization
- Isolation> 30 dB
- F / B> 35 dB
- Horizontal beamwidth 5 °
- Vertical beamwidth 5 °
- Maximum power per port 50 W
- 50Ω impedance
Mechanical Specification
- C5x connector
- Weight 6.5 kg
- Diameter suitable for mast or tower 30 cm to 80 cm
- Operating temperature -40 ° C to + 70 ° C (-32 ° F to + 158 ° F)
Key Features
- High 30 dBi Gain for Maximum Long-Distance Performance
- Dual Polarization With 45° and 90° Configuration Options
- Front-to-Back Ratio of 35 dB for Superior Signal Isolation
- Integrated C5x or B5x Connector for Direct Connection
- Universal Mast Mount for 12-31 in Diameter Poles
- Operates in Extreme Temperatures From -40°F to 158°F
