Ubiquiti UA-RESCUE Access Rescue KeySwitch COM/NO/NC 18-24 AWG

The Ubiquiti UA-Rescue is a purpose-built manual key switch designed to provide reliable human override capability for both fail-safe and fail-secure electronic lock systems. When a door controller or access control system malfunctions, the UA-Rescue gives authorized personnel a direct, hardware-level means of restoring access or maintaining lockdown without depending on software or network connectivity. Its COM/NO/NC terminal block architecture makes it straightforward to wire into virtually any standard access control circuit, while the brass internal wave key mechanism delivers the tactile durability expected in life-safety and emergency egress applications. Housed in a polycarbonate enclosure rated for a wide operating temperature range, the UA-Rescue is suited for deployment in demanding commercial, industrial, and institutional environments where code compliance and operational continuity are non-negotiable.

Key features & benefits

• Manual Override for Fail-Safe and Fail-Secure Locks — Provides a direct, hardware-level override for either fail-safe or fail-secure lock configurations, giving security personnel immediate control when electronic systems are unavailable or malfunctioning.
• COM/NO/NC Terminal Block — Three-terminal configuration supports normally open and normally closed circuit wiring in a single device, offering flexibility to integrate with a wide range of access control panels and relay circuits.
• 18–24 AWG Wiring Support — Compatible with common low-voltage control wire gauges used throughout commercial access control installations, simplifying integration with existing cable infrastructure.
• Brass Internal Wave Key Mechanism — The brass wave key cylinder provides a durable, pick-resistant locking action appropriate for security-sensitive applications where key control is critical.
• Polycarbonate Enclosure — Impact-resistant polycarbonate housing protects internal components against physical stress and environmental exposure across a broad installation range.
• 28VDC, 4A Switch Rating — Rated to handle 28VDC at 4A, covering the control voltage and current levels typical of professional access control and electrified lock systems.
• Two Keys Included — Ships with two keys, enabling primary use and a secure backup without requiring additional key orders at installation time.
• FCC, IC, and CE Certified — Carries FCC, IC, and CE certifications, supporting deployment in North American and European-regulated installations.
