ACCESSPRO
Accesspro XBS-5000-L Left Vehicle Barrier 18ft Arm 250W Gray
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
- Max. arm length: 18 feet (5 meters).
- Cabinet color: Gray
- Aperture speed: 6 seconds
- Parameter adjustment via controller card
- Consumption: 250W
- Stand-by consumption: 2W
- Semi-intensive use
- Operating voltage: 110V
- Operating temperature -20 to 50°C.
- Relative humidity <90%.
- Includes 2 controls XBT23 (supports a max. of 5 controls with button installation).
Left vehicle barrier, gray color, compatible with 18 feet gate arm (Not included)
Additional Characteristics:
- The product is assembled in Mexico
- The parameters of the product can be programmed
- Programmable automatic closure
- Supports illuminated arm of up to 18 feet (5 meters)
- Operation of up to 150 cycles per hour.
AccessPRO's XBS-5000 barriers include a mechanism equipped with an encoder that allows the controller card to electronically adjust the limit switches, achieving a smoother and more accurate movement when opening and closing.
NOTE: Consider an armrest XB-POST for 13 ft arms or longer to avoid early damage to the mechanism.
What accessories do I need for the installation?
Step one: Select your lane arm according to the application.
XB-TELESC-ARM Telescopic arm, non-illuminated, adjustable arm length from 13 to 18 feet, compatible with break away system XBA-DROP-ARM
XBS-ARM 18 feet illuminated arm RED/GREEN, requires additional power source PS-12-DC-4C
Step two: Safety and installation accessories.
XB-ANCLA Fixing anchor for AccessPRO barriers
XB-POST Lane arm-rest post, necessary for arms longer than 13 feet.
XBS-SW-01 3-push button control station for barriers and motors.
XBS-IR33 Security infrared photocell with up to a 10 meter range
XB-DLP-1101 Mass sensor in a channel, requires power source PL-DC-1000 and a magnetic loop SYS-LM8
XBS-RDA06 Radar for AccessPRO barriers with a 6-meter range.
XB-REC2 Wireless receiver for 400 controls (adding a button per channel), compatible with transmitters XBT-23 keyfob control, XBT-18-BC control with visor cllip, and XB-WT-01 wall type control.
10LZR-H100KIT-19327 Laser sensor for security with a range of 9.6 x 9.6 meters, replace magnetic loops
PRO-LIGHT-LED Green/Red traffic light, requires mounting XB-ML.
Key Features
- Precision Encoder for Smooth and Accurate Arm Movement
- Low Power Consumption at Only 2W in Standby Mode
- Operates in Temperatures From -4°F to 122°F
- Includes 2 Wireless Controls With Support for 5 Total
- 110V Operation With Semi-Intensive Duty Rating
- Supports Additional Safety Accessories and Illuminated Arms
