ACCESSPRO
Accesspro XBS-6M-L Left Vehicle Barrier 6-Second Opening 120W 127VAC
Product identifier
SKU
XBS-6M-L
$637.49
Available to order
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
Key features:
- Supports telescopic arm up to 20ft (6 meters)
- Left barrier
- Opening time 6 seconds
Physical and Electrical Features:
- Operating voltage 127 Vac
- Consumption 120 W
- Up to 2400 daily cycles
Additional features:
- Operating temperature -20 to 50°C
- Mechanism torque 150 Nm
- Motor rotation 1500 r
- FCC Certification
Left vehicle barrier compatible with telescopic arm up to 6 meters (Not included).
Optional accessories not included:
- XBS-SW-01 Triple heavy-duty button panel
- XB-T23 Keychain wireless control
- XB-T18-BC Visor wireless control
- XB-REC2 External wireless receiver
- XB-DLP-1101 Single-channel mass sensor
- SYS-LM8 8-meter magnetic loop
- XBS-IR-33 Safety photocell
- XB-TEL-ARMB1 6-meter telescopic arm
- XBS-RDA06 ACCESS-PRO barrier radar
- XB-WT-01 Wall button for ACCESS-PRO barriers
- XB-ANCLA Anchor for ACCESS-PRO barriers
NOTE: Consider using XB-POST armrests for arms of 4 meters or more to prevent premature mechanism damage.
ADDITIONAL NOTES
The barrier is prepared to work with an arm with a distance of 5 to 6 meters. Having an arm with a different distance requires changing springs.
To know what type of spring should be used, we can refer to the following
Barrier only compatible with XB-TEL-ARMB1 arm.
In a correct adjustment of the opening and closing limits, our mechanism should not reach the physical limits.
If your mechanism is reaching the physical limits, please review the following VIDEO.
NOT compatible with illuminated arms.
Key Features
- Supports Telescopic Arms up to 20 ft in Length
- Fast 6-Second Opening Cycle for Quick Vehicle Access
- 120V AC Operation With Low 120W Power Consumption
- Extreme Temperature Operation From -4°F to 122°F
- High Torque 150 Nm Mechanism for Reliable Performance
- Up to 2400 Daily Operation Cycles for Heavy Traffic
