YEALINK
Yealink EXP20 20-Key LCD Expansion Module 160x320 Backlit Display
Lead time confirmed after order.
- Product availability confirmed before fulfillment.
- Support in English, Spanish and Portuguese.
- 30-day returns and RMA support.
Product details
PRODUCT SPECIFICATIONS
Yealink EXP20
The Yealink EXP20 is the next iteration of the company’s flexible and powerful SIP-T27P and SIP-T29G advanced IP phone models.
The EXP20 contains a large and user-friendly liquid crystal display (LCD) interface that measures 160x320 pixels, as well as contains 20 physical, dual-color LED keys. The additional screen space and added number of buttons simplifies user navigation and streamlines essential operational functions such as speed dial, BLF, BLA, call forwarding, transfer and hold. Up to six EXP20 phone systems can be strung together on a single daisy chain.
The advanced new Yealink EXP20 is an ideal IP phone system for receptionists, administrative assistants or contact center workers who need to monitor and manage a large volume of calls on a regular basis.
Key Features:
- A diverse range of actionable,LCD-accessible icons
- 160x320 graphic LCD with backlight
- 20 physical, dual-color LED programmable keys
- 18 aditional keys available
- Supports up to six modules
- Two accessible pages
- Stand with two adjustable angles
- Two or less expansion modules can be powered by the host phone
Technical Description:
-
Display:
- 160x320 graphic LCD
- LCD Backlight
- Two accessible pages
- A diverse range of actionable, LCD-accessible icons
-
Features Keys and Indicator:
- 20 physical, dual-color LED programmable keys
- 18 additional keys available
- Programmable keys enable users to partake in advanced call functions such as: BLF list, multi-person conferencing, call forwarding, LDAP, XML browser functionality functionality
-
Physical Features:
- Stand with two adjustable angles
- Two or less expansion modules can be powered by the host phone
- Supports up to six modules
- 2xRJ12 (6P6C) ports for data in and out
- Max power consumption (PSU): 0.67W
- Dimension (W x D x H x T): 122mm x 143mm x 110mm x 45mm
- Applies to Yealink SIP-T27G/SIP-T27P/ SIP-T29G
- Operating temperature: -10~50°C (+14~122 °F)
- Operating humidity: 10%-95%
-
Package Features:
- Qty/CTN: 20 PCS
- N.W/CTN: 8.0 kg
- G.W/CTN: 8.8 kg
- Giftbox size: 169mm x 133mm x 82mm
- Carton Meas: 455mm x 366mm x 314mm
