Yeastar YST-TA1600 NeoGate TA 16-Port Analog VoIP Gateway SIP

PRODUCT OVERVIEW

NeoGate TA Analog VoIP Gateways are cutting-edge products that connect legacy telephones, fax machines and PBX systems with IP telephony networks and IP-based PBX systems.

PRODUCT TYPE

IP Phones

KEY FEATURES

• Number of Telephony Ports: 16
• Phone Interface: 16 x RJ11 FXS ports plus 1 x 50 pin
• Telco connector
• Protocol: SIP (RFC3261), IAX2
• Transport Protocol: UDP, TCP, TLS, SRTP
• DTMF: RFC2833, SIP INFO, In-band
• Codec: G.711 a/u-law, G.722, G.726, G.729a, GSM,
• ADPCM, Speex
• Echo Cancellation: ITU-T G.168 LEC
• FAX over IP: T.38 and pass-through
• Signalling: Kewl Start, Loop Start
• Caller ID: BELL202, ETSI (V23), NTT (V23-Japan), and
• DTMF-based CID
• Disconnect Method: Busy Tone, Polarity Reversal
• LAN: 1 (10/100Mbps)
• Network: Static IP, DHCP Client, Firewall, VLAN, DDNS,
• QoS, OpenVPN
• NAT Traversal: Static NAT, STUN

TECHNICAL SPECIFICATIONS

• Brand: Yeastar
• Model: YST-TA1600
• Product Type: IP Phones
• Number of Telephony Ports: 16
• Phone Interface: 16 x RJ11 FXS ports plus 1 x 50 pin
• Telco connector
• Protocol: SIP (RFC3261), IAX2
• Transport Protocol: UDP, TCP, TLS, SRTP
• DTMF: RFC2833, SIP INFO, In-band
• Codec: G.711 a/u-law, G.722, G.726, G.729a, GSM,
• ADPCM, Speex
• Echo Cancellation: ITU-T G.168 LEC
• FAX over IP: T.38 and pass-through
• Signalling: Kewl Start, Loop Start
• Caller ID: BELL202, ETSI (V23), NTT (V23-Japan), and
• DTMF-based CID
• Disconnect Method: Busy Tone, Polarity Reversal
• LAN: 1 (10/100Mbps)
• Network: Static IP, DHCP Client, Firewall, VLAN, DDNS,
• QoS, OpenVPN
• NAT Traversal: Static NAT, STUN
• Size: 440 (L) mm x 250 (W) mm x 24 (H) mm
• Power Supply: AC 100~240V/50~60Hz
• Operation Range: 0° to 50°C, 32° to 122° F
• Storage Range: -20° to 65°C, 4° to 149° F
• Humidity: 10-90% non-condensing

INTENDED USE / APPLICATIONS

• Business voice communications
• Office, reception, and institutional environments
• Integration with compatible SIP/VoIP systems
